INSTALLATION MANUAL
NOISE MASKING MODULE
1. GENERAL DESCRIPTION
The NM-01 is a noise masking module to be used in conjunction with TOA’s 9000M2, 900, 700 and BG-2000 series
amplifiers. This module generates a noise source to be used for sound masking and audio privacy applications. Such
applications include open-plan office environments or smaller spaces where distracting or private conversations need
to be made unintelligible. The module allows connection of optional external signal processing equipment (e.g. an
equalizer), as required. A simple contact allows for muting of this noise source, if desired.
2. CONNECTIONS
An external mute switch and/or an external processor can be connected as options. (The right side pin of the 3P
terminal block is not used.)
NM
-
01
<When using without an external processor>
<When using with an external processor>
Mute
Switch
Supplied RCA Cable
Output
Input
External
Processor
Mute Switch
3. SPECIFICATIONS
Power Source 24 V DC (Supplied from amplifier)
Current Consumption 10mA
Output Level (to amplifier) 300mV
Noise Type Analog random pink noise
Mute Function Dry contact, normally open (close to mute)
Input 10kΩ, RCA pin jack
Output 150mV, 600Ω, RCA pin jack
Dimensions 35(W) x 78(H) x 88(D)mm (1.38” x 3.07” x 3.46”)
Weight 64g (0.14lb)
Supplied Accessary Stereo RCA cable
NM-01
MUTE
IN
OUT
35mm (1.38”) 88mm (3.46”)
78mm (3.07”)
