INSTALLATION MANUAL

MATRIX SYSTEM SX-2000 SERIES

When an EN 54-16 compliant SX-2000 system has to be installed, then read "APPENDIX: ADDITIONAL

INSTALLATION INSTRUCTIONS FOR AN EN 54-16 COMPLIANT SYSTEM" in this document carefully

and follow up the installation and configuration requirements explained herein. This APPENDIX contains

the basic description of settings and installations, so please refer to the general instruction sections in

this document for more details.

Note

Refer to the Instruction Manual attached to the VX-2000DS for the installation of the the VX-2000DS

Emergency power supply, the VX-2000PF Power supply frame, and the VX-200PS Power supply unit.

1134

TOA Electronics Europe GmbH

Suederstrasse 282, 20537 Hamburg, Germany

The year when the CE mark was affixed on the product

is indicated by the first two digits of the serial number.

1134-CPD-102

EN 54-16: 2008

Fire detection and fire alarm systems

— Part 16: Voice alarm control and indicating equipment

Options:

Emergency microphone(s)

Manual reset of the voice alarm condition

Indication of faults related to voice alarm zones

Phased evacuation

Voice alarm condition output to CIE

Redundant power amplifiers

Thank you for purchasing TOA's Matrix System.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

2
TABLE OF CONTENTS
NOMENCLATURE AND FUNCTIONS
1. SX-2000SM System Manager .................................................................................. 6
2. SX-2000AI Audio Input Unit ................................................................................... 10
3. SX-2100AI Audio Input Unit ................................................................................... 15
4. SX-2000AO Audio Output Unit ............................................................................... 20
5. SX-2100AO Audio Output Unit ............................................................................... 26
6. SX-2000CI Control Input Unit ................................................................................. 32
7. SX-2000CO Control Output Unit ............................................................................ 34
8. RM-200SF Fireman's Microphone ......................................................................... 36
9. RM-200SA Remote Microphone ............................................................................ 39
10. RM-210 Remote Microphone Extension ................................................................ 42
11. RM-200RJ Terminal Unit ........................................................................................ 43
12. Optional Modules
12.1. SX-200RM Remote Microphone Interface Module  .................................... 44
12.2. D-921E Microphone/Line Input Module ...................................................... 45
12.3. D-921F Microphone/Line Input Module ...................................................... 45
12.4. D-922E Microphone/Line Input Module ...................................................... 46
12.5. D-922F Microphone/Line Input Module ...................................................... 46
12.6. D-936R Stereo Input Module ..................................................................... 47
13. VP-2064, VP-2122, VP-2241, and VP-2421 Power Amplifiers .............................. 48
14. VP-200VX Power Amplifier Input Module ............................................................... 48
INSTALLATION
1. SX-2000SM
1.1. System reset enable/disable settings (DIP switch 3 operation) ................... 49
1.2. Failure reset operation method settings (DIP switch 4 operation)  ............... 50
2. SX-2000AI and SX-2100AI
2.1. Module installation ....................................................................................... 51
2.2. Setting the device number ........................................................................... 52
2.3. Changing the type of control outputs (SX-2100AI only) ............................... 53
3. SX-2000AO and SX-2100AO
3.1. Setting the device number  ........................................................................... 55
3.2. 24 V Emergency cutoff input settings (DIP switch 8 operation)
(SX-2000AO only) ........................................................................................ 56
3.3. Converting an output into a transformer-balanced output
(SX-2000AO only)  ........................................................................................ 57
3.4. Changing the method of power supply for the control input signal
applied to the Local Audio Control Input Terminal (SX-2100AO only) ......... 60
4. SX-2000CO ............................................................................................................ 62
5. RM-200SF, RM-200SA, and RM-210
5.1. RM-200SF and RM-200SA device number settings
(DIP switches 1 – 3 operation) ..................................................................... 64
5.2. Adjusting microphone sensitivity (RM-200SF: DIP switch 5 operation
or RM-200SA: DIP switch 4 operation) ........................................................ 66
5.3. CPU OFF function (general urgency all-call) settings
(RM-200SF:DIP switch 6 operation or RM-200SA: DIP switch 5 operation)
..... 68
5.4. RM Communication function setting
(RM-200SF: DIP switch 4 operation or RM-200SA: DIP switch 6 operation)
.... 69
5.5. Using an external microphone (RM-200SA only) ......................................... 70
5.6. Compressor function setting  ........................................................................ 72
5.7. Microphone fault detection function settings (RM-200SA only)  ................... 74
