INSTRUCTION MANUAL
COLUMN SPEAKER TZ-200BS
TZ-400BS
Thank you for purchasing TOA’s Column Speaker.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1. SAFETY PRECAUTIONS
・Be sure to read the instructions in this section
carefully before use.
・Make sure to observe the instructions in this manual
as the conventions of safety symbols and messages
regarded as very important precautions are included.
・We also recommend you keep this instruction
manual handy for future reference.
WARNING
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
When Installing the Unit
・Install the speaker only in a location that can
structurally support the weight of the speaker and the
mounting bracket. Doing otherwise may result in the
unit falling down and causing personal injury and/or
property damage.
・Be sure to use the supplied mounting bracket in
combination. Doing otherwise may cause the
speaker to fall, resulting in personal injury.
・Refer all the installation work to TOA dealer from
whom the speaker was purchased. Installation work
requires extensive technical knowledge and
experience. The speaker may fall off it incorrectly
installed, resulting in possible personal injury.
・Owing to the unit’s size and weight, be sure that at
least two persons are available to install the unit.
Failure to do so could result in personal injury.
・Do not use other methods than specified to install the
speaker and the bracket. Extreme force is applied to
the speaker and the speaker could fall off, possibly
resulting in personal injuries.
・Use screws that are appropriate for the wall’s
material and structure. Failure to do so may cause
the speaker to fall, resulting in material damage and
possible personal injury.
・Ensure that all screws are securely tightened. If they
are loose after installation, the speaker could fall
down, possibly resulting in personal injury.
・Do not mount the speaker in locations exposed to
constant vibration. The speaker or its mounts can be
damaged by excessive vibration, potentially causing
the speaker to fall, which could result in personal
injury.
・Do not use anti-rust lubricant. If it contacts resin or
rubber parts, they could deteriorate and cause the
speaker to fall, possibly resulting in personal injury.
・Avoid installing the speaker near seaside or in
locations exposed to corrosive gas. The speaker or
its parts may be subject to corrosion, which might
cause it to fall or resulting personal injury.
・Do not install the speaker in indoor swimming pools
or such locations where liquid chemicals are used.
The parts deteriorate if corroded, causing the
speaker to fall, which could result in personal injury.
When the Unit is in Use
・If any of the following irregularities occurs,
immediately switch off the amplifier's power, and
inform TOA dealer from where the speaker was
purchased. Further using the speaker may result in
fire or electric shock.
・If you detect smoke or a strange smell coming
from the speaker
・If water or any metallic object gets into the speaker
・If the speaker falls, or the speaker case breaks
・To prevent a fire or electric shock, never open nor
remove the speaker case. Refer all servicing to your
nearest TOA dealer.
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
When Installing the Unit
・Avoid touching the speaker's sharp metal edge to
prevent injury.
・To avoid electric shocks, be sure to switch off the
amplifier's power when connecting speakers.
When the Unit is in Use
・Do not place heavy objects on the speaker as this may
cause it to fall or break which may result in personal
injury and/or property damage. In addition, the object
itself may fall off and cause injury and/or damage.
・Do not stand or sit on, nor hang down from the
speaker as this may cause it to fall down or drop,
resulting in personal injury and/or property damage.
・Do not operate the speaker for an extended period of
time with the sound distorting. Doing so may cause the
connected speakers to heat, resulting in a fire.
・Have the speaker checked periodically by TOA dealer
from where it was purchased. Failure to do so may
result in corrosion or damage to the speaker or the
mounts that could cause it to fall, possibly causing
personal injury.
・No naked flame sources, such as lighted candles,
should be placed on the speaker.
2. GENERAL DESCRIPTION AND FEATURES
TOA's TZ-200BS, TZ-400BS wall mount column speakers feature an aluminum made housing and grill designed
for indoor and outdoor installation. The speakers can be easily installed using the adjustable speaker mounting
brackets included. The speakers come with screw type steatite terminal blocks and thermal fuse. They are certified
according to the European Standard EN 54-24:2008 and compliant with the British Standard BS 5839-8:2008
3. INTERNAL CIRCUIT DIAGRAM, APPEARANCE AND FUNCTIONS
TZ-200BS internal circuit diagram
TZ-400BS internal circuit diagram
When shipped from the factory, the speaker is internally connected as shown above.
To change the impedance, refer to “4.1. Set the input power”.
[Front]
[Side] [Rear]
Tweeter
Woofer
2
Cable gland
APPEARANCE (This figure represents the TZ-400BS.)
