Side 1/11

TOA Electronics Europe GmbH 1

d Instruction Manual

Loop-Isolator Monitor VX-3000IM-EB

Thank you for purchasing TOA’s Loop-Isolator Manager of the Integrated Voice Evacuation

System VX-3000.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your

equipment

1134

TOA Electronics Europe GmbH

Süderstraße 282, 20537 Hamburg, Germany

1134-CPR-195

DoP 21-004

EN 54-16: 2008

Fire Detection and fire alarm systems - part 16: Voice alarm control and

indication system for fire detection and fire alarm systems for buildings

Options:

Manual silencing of voice alarm condition

Manual reset of voice alarm condition

Voice alarm condition output

Indication of a fault related to voice alarm zones

Voice alarm manual control

Emergency microphones

Redundant power amplifiers

TOA Electronics Europe GmbH
CONTENTS
 SAFETY PRECAUTIONS .......................................................................... 3
 GENERAL DESCRIPTION ........................................................................ 4
 NOMENCLATURE .................................................................................. 5
 INSTALLATION ...................................................................................... 5
 CONNECTIONS ...................................................................................... 6
1.  Loudspeaker Line Connections ............................................................................... 6
1.1.  Connection between a single amplifier output and a single loop ................................. 6
1.2.  Connection between a single amplifier output and a several loops .............................. 6
2.  Connection of the Fault Outputs to the VX-3000F ................................................... 8
 Settings in the VX-3000 Setting Software .............................................. 8
1.  Relation between Control Inputs and Failure Outputs ............................................ 8
2.  Software Settings .................................................................................................. 8
2.1.  Basic Settings .................................................................................................................. 9
2.2.  Surveillance Settings ....................................................................................................... 9
2.3.  General Failure: Pattern Settings in Tab “Failure” ....................................................... 10
 SPECIFICATIONS .................................................................................. 11
 ACCESSORIES ....................................................................................... 11

Remark:
VX-3000F stands for any of the frames VX-3004F, VX-3008F and VX-3016F.
