SETTING SOFTWARE INSTRUCTIONS

INTEGRATED VOICE EVACUATION SYSTEM

VX-3000 SERIES

Thank you for purchasing TOA’s Integrated Voice Evacuation System.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

Tips

• In this manual, the VX-3004F/3008F/3016F Voice Evacuation Frames are collectively referred to as

"VX-3000F."

• Set the VX-3308WM as the VX-3008F.

For Authorized Administrator and Installer

TABLE OF CONTENTS

Chapter 1 : SETTING SOFTWARE OUTLINE

1. SOFTWARE OUTLINE ................................................................................ 1-2

2. NOTES ON PERFORMING SETTINGS ........................................... 1-2

2.1. System Requirements ....................................................................................... 1-2

2.2. Notes ................................................................................................................. 1-2

3. SOFTWARE SETUP ..................................................................................... 1-3

3.1. Setting Software Installation .............................................................................. 1-3

3.2. Uninstallation .................................................................................................... 1-5

4. STARTING THE VX-3000 SETTING SOFTWARE .................... 1-6

5. SELECTING A USER .................................................................................. 1-7

6. SIMPLE MODE AND NORMAL MODE ............................................ 1-7

Chapter 2 : USING IN THE SIMPLE MODE

1. SETTING TO THE SIMPLE MODE ..................................................... 2-2

2. FUNCTIONS ENABLED WITH THE SIMPLE MODE ............. 2-3

3. SETTING PROCEDURE ........................................................................... 2-4

3.1. When Creating a Setting Project File in Advance ............................................ 2-4

3.2. When Creating the Setting Project File at the Installation Site ........................ 2-5

4. SETTING ITEM ............................................................................................... 2-6

4.1. Setting Item Button Configuration .................................................................... 2-6

4.2. Menu Bar .......................................................................................................... 2-6

5. CREATE A NEW SETTING PROJECT FILE ............................... 2-8

6. BASIC SETTINGS ....................................................................................... 2-20

7. UNIT CONFIGURATION SETTINGS ................................................ 2-21

7.1. Adding the VX-3000F to the Unit Configuration .............................................. 2-22

7.2. Deleting the VX-3000F from the Unit Configuration ........................................ 2-24

7.3. Adding the Remote Microphone to the RM Configuration ............................... 2-24

7.4. Deleting the Remote Microphone from the RM Configuration ........................ 2-25

7.5. Setting the VX-3000F’s Unit Configuration ..................................................... 2-25

7.6. Setting the Remote Microphone Configuration ............................................... 2-28

8. PRIORITY SETTINGS ............................................................................... 2-31

9. BROADCAST SETTING ......................................................................... 2-34

9.1. General Broadcast Setting ............................................................................. 2-34

9.2. Control Output Setting .................................................................................... 2-37

Produkspesifikasjoner

Merke:	Toa
Kategori:	Ikke kategorisert
Modell:	VX-3004F
Vekt:	7600 g
Bredde:	482 mm
Dybde:	345 mm
Høyde:	132.6 mm
Inngangsspenning:	31 V
Produktfarge:	Sort
Strømforbruk (vanlig bruk):	85 W
Driftstemperatur (T-T):	-5 - 45 °C
Bærekraftsertifikater:	CE
Signal-til-støy-forhold (SNR):	60 dB
Kroppsmateriale:	Stål
Antall RJ45-porter:	12
Dekselfarge:	Sort
Bærekraftsamsvar:	Ja
Frekvensrekkevidde:	40 - 20000 Hz
Total harmonisk forvrengning pluss Noise (THD + N)(1 kHz):	1
