INSTRUCTION MANUAL
TRANTEC
ANTENNA BOOSTER
YW-7000
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
WARNING
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
CAUTION
1. SAFETY PRECAUTIONS
• Beforeinstallationoruse,besuretocarefullyread
all the instructions in this section for correct and
safe operation.
• Besuretofollowalltheprecautionaryinstructions
in this section, which contain important warnings
and/or cautions regarding safety.
• After reading, keep this manual handy for future
reference.
• Do not expose the unit to rain or an environment
whereitmaybesplashedbywaterorotherliquids,
asdoingsomayresultinreorelectricshock.
• Since the unit is designed for indoor use, do not
install it outdoors. If installed outdoors, the aging of
parts causes the unit to fall off, resulting in personal
injury. Also, when it gets wet with rain, there is a
dangerofelectricshock.
• Use nuts and bolts that are appropriate for the
ceiling’s or wall’s structure and composition. Failure
to do so may cause the unit to fall, resulting in
materialdamageandpossiblepersonalinjury.
• Neveropennorremovetheunitcasetopreventa
re or electric shock that may occur when power
isaccidentallyshort-circuited.Referallservicingto
qualiedservicepersonnel.
• Do not touch this unit and antenna cable during
thunder and lightning, as this may result in electric
shock.
• Neverplug in nor remove the antenna cable with
wethands,asdoingsomaycauseelectricshock.
• Leave theinstallation oftheantennato your TOA
dealer because the installation requires expert
knowledge. Improper installation may cause the
antenna to fall, resulting in personal injury or electric
shock.
• When connecting the antenna cable, turn off the
tuner’s or antennadistributor’s power.
Doingotherwisemaycauseelectricshock.
• Donotforciblypullontheantennacable,asdoing
somaycausetheconnecteddevicetofall,resulting
in personal injury.
• Be sure to disconnect the antenna cable when
moving the antenna. Otherwise, people may trip
overtheantennacableandtheconnecteddevice
may fall, resulting in personal injury.
• Donotdamagetheantennacable.Ifdamaged,this
mayresultinreorelectricshock.Wheninserting
orremovingtheantennacable,besuretograspits
connector.
• Neverplacetheunitnearheatersnorheatit.
Installtheantennacableatalocationwhereitisnot
carelessly damaged.
If damaged, replace it with a new one.
FCC Compliance
This device complies with Part 15 of the FCC Rules.
Operationissubjecttothefollowingtwoconditions:
(1) thisdevicemaynotcauseharmfulinterference,and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Anymodicationsmadetothisdevicethatarenotapproved
by TOA Corporation may void the authority granted the
userbytheFCCtooperatethisequipment.
Note:Thisequipmenthasbeentestedandfoundtocomply
withthelimitsforaClassBdigitaldevice,pursuanttoPart
15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
andcanradiateradiofrequencyenergyand,ifnotinstalled
and used in accordance with the instructions, may cause
harmfulinterferencewithradiocommunications.However,
there is no guarantee that interference will not occur in a
particularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbe
determinedbyturningtheequipmentoffandon,theuser
isencouragedtotrytocorrecttheinterferencebyoneor
moreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandthe
receiver.
• Connecttheequipmentintoanoutletonacircuitdifferent
fromthattowhichthereceiverisconnected.
• Consult the dealer or an experienced radio/television
technician for help.
2. GENERAL DESCRIPTION
TheYW-7000isanantennaboosterdesignedforusetocompensateforhighfrequencyloss(cableloss)thatoccurswhen
theantennacableisextended.
ItisusedincombinationwiththeoptionalYW-7520orYW-7570WirelessAntenna.
Sincepowerissuppliedfromtheantennainputterminalofthewirelesstuner,theYW-7000operatesbysimplyconnecting
theantennacabletoit.
3. HANDLING PRECAUTIONS
• TheunitcannotbeusedwithadirectmountL-typeantenna.
• Donotinstalltheunitatfollowinglocations.Doingsomaycausedamagetotheunit.
· Locationsdirectlyexposedtorainsuchasoutdoorsorundertheeaves.
· Locationswithhighhumidordust.
· Locationsexposedtothedirectsunlightornearheaters.
· Locationsgeneratingsootysmokeorsteam.
• Donotusecountersunkheadscrewtomounttheunit,asthescrewwidensthemountinghole,causingdamagetothe
unit.
4. CONNECTION
Notes
• Only1unitcanbeconnectedperantenna.
• Iftheunitisconnectedinreverse(antennasideandtunerside),itwillnotoperate.
5. TYPE OF COAXIAL CABLE VS. ALLOWABLE LENGTH
For the maximum cable
distance,refertothetable
at right.
TraceabilityInformationforEurope(EMCdirective2004/108/EC)
Manufacturer:
TOACorporation
7-2-1,Minatojima-Nakamachi,Chuo-ku,Kobe,Hyogo,Japan
Authorizedrepresentative:
TOAElectronicsEuropeGmbH
Suederstrasse282,20537Hamburg,Germany
133-07-308-7A
URL:http://www.toa.jp/
YW-7520 or YW-7570
Connect the booster at the halfway point of the antenna cable.
If difficult to do so, connect it at the point close to the antenna
from the intermediate point.
Antenna side Tuner side
Antenna
input
Antenna cable (coaxial cable)
Wireless tuner
or
Antenna distributor
CableType ExternalDiameter
Max.lengthwhenusing Max.lengthwhen
the antenna alone theYW-7000isused
RG-6/U 8.4mm(0.33")
10m(10.94yd)
35m(38.28yd)
RG-11/U 10.3mm(0.41") 50m(54.68yd)
Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
• Accessory
BNCcable50cm(1.64ft) ....................................1
6. SPECIFICATIONS
PowerSource 7–12VDC
CurrentConsumption 35mA
Type DCpasstypeboosteramplier
FrequencyRange 606–638MHz(Gband),
722–752MHz(Bband)
Gain Approx.10dB
NoiseFactor Under3dB
MaximumInput Under100dBμV
Input/OutputConnector BNCjacks
Input/OutputImpedance 50Ω
OperatingTemperature –10to+50ºC(14to122˚F)
Weight 50g(0.11lb)
Dimensions 57(w)x76(h)x26(d)mm
(2.24”x2.99”x1.02”)
