Side 1/46
English 1
Coffee
Machine
Milk
Frother
TCM-9008A-GS
OWNER
MANUAL
English 2
Technical Data
Voltage: 220-240V~50-60Hz
Power: 1350W Capacity: 1.5L
Important Safeguards
When using electrical appliances, basic precautions
should always be followed, including the following:
1. Before using check that the voltage power
corresponds to the one shown on the appliance
nameplate.
2. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
3. Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and they understand the
hazards involved.
4. Keeptheapplianceanditscordoutofreachofchildren.
5. This appliance shall not be used by children.
Children should be supervised to ensure that they
do not play with the appliance.
6. Close supervision is necessary when any appliance
is used by or near children.
7. Cleaning and use rmaintenance shall not be made
by children unless the yare supervised.
8. To disconnect, turn any control to “OFF”, remove
plug from wall outlet. Always hold the plug. But
never pull the cord.
9. Unplug from outlet when not in use and before
cleaning. Allow to cooling before putting on or
taking off parts, and before cleaning the appliance.
10. The use of accessory not recommended by the
appliance manufacturer may result in re, electric
shock or injury to persons.
11. Do not use outdoors.
12. Do not use appliance for other than intended use.
13. Do not let cord hang over edge of table or
counter,or touch hot surface.
14. Do not place on or near a hot gas or electric
burner,or in a heated oven.
15. Do not let the coffee machine operate without
water.
16. To protect against re, electric shock and injury to
persons do not immerse cord, plug, or in water or
other liquid.
17. Do no tset a hot container on a hot or cold surface.
18. The container is designed for use with this appliance.
It must never be used on a range top
19. Do not clean container with cleansers, steel wool
pads, or other abrasive material.
20. Be careful not to get burned by the steam during
the brewing cycles.
21. Some parts of appliance are hot when operated, so
do not touch with hand. Use handles or knobs only.
22. The appliance must not be immersed.
23. This appliance is intended to be used in household
and similar applications such as:
– staff kitchen areas in shops, ofces and other working
environments;
– farm houses;
– by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments;
– indoor areas for private homes and home
environments;
– the place with an altitude not higher than 2000m.
24. A warning of potential injury from misuse.
25. The heating element surface is subject to residual
heat after use.
26. The coffee-maker shall not be placed in a cabinet
when in use.
27. Switch off the appliance and disconnect from
supply before changing accessories or approaching
parts that move in use.
28. CAUTION: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out, this
appliance must not be supplied through an external
switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by the
utility.
29. Always disconnect the appliance from the supply
if it is left unattended and before assembling,
disassembling or cleaning.
30. Follow the instructions above, including the
instructions in the section CLEANING AND
MAINTENANCE.
31. Save these instructions.
Know Your Coffeemachine
Control Panel
English 3
Before First Use
Check that all accessories are complete and the unit is
not damaged. Check and understand all the parts and
their functions. It is recommended to keep the original
packaging for future use.
And then follow the operations as below.
1. Before using for the rst use, please remove the water
tank, milk reservoir, brewer and milk frother and rinse them
with clean water.
2. Check and make sure all the removable parts are
installed well in position:
1) Water tank:
Fill the water tank with fresh water up to Max mark and
then reassembly it into the unit and make sure it is properly
assembled, and then close the water tank lid.
2) Milk reservoir:
1. Insert the milk tube into the hole of milk frother at the side
of coffee outlet.
2. Move the milk tube from the milk reservoir lid and then
insert it into the milk reservoir lid.
3. Install the milk reservoir and milk reservoir lid well in
position.
The milk tube can be folded, and please install it rmly by
yourself if it is loose.
3) Grind setting knob
1. Turn the grind setting knob bracket counterclockwise to
the leftmost.
2. Cover the grind setting knob according to the specied
position.
3. Select the grinding setting clockwise.
NOTE: When the new coffee machine is used for the rst
time, it is suggested that the grind setting higher than
setting 8 shall be selected. The adjustable grind settings
range between 1(nest) and 15(coarsest), the number on
the grind setting knob pointed by the arrow is the actual
selected grind setting.
CAUTION: We suggest to adjust one notch at one time to
avoid the damage.
4) Milk frother
1. Open the coffee outlet cover and make sure the milk
frother is installed well in position.
2. If the milk frotehr is installed well in position, please
close the coffee outlet cover and then insert the
connecting tube.
3. Insert the other end of the connecting tube into the milk
reservoir.
5) Adjustment for the height of coffee outlet
The adjustable height of coffee outlet ranges between 85
and 115mm.
6) Brewer
1. Open the door and check whether the brewer is
installed well in position.
A. Check whether the arrow of the brewer is aligned
with the arrow of the upper bracket
B. An audible click indicates that the assembling of
brewer is correct .
C. The warning indicator “ ”will light solidly if the brewer is
not installed in place.
2. Closethedoor
A. The whole door and body are on the same horizontal
plane.
B. The warning indicator “ ”will ash if the door is not
closed properly.
7) lnner drip tray and residue-collection container
Open the door and check whether the drip tray is installed
in place.
1. Open the door and check whether the residue-collection
container is installed in place.
The inner drip tray will not be installed well in position, the
warning indicator “ ”will ash and the machine can not
work if there is foreign object at the front of the residue-
collection container.
8) Drip plate
1. Place the drip plate on the drip tray. The drip plate must
be installed well in position so that the container can be
placed on it for holding coffee, milk or hot water.
2. Insert the drip tray into the appliance.
NOTE: The drip tray collects the water from the dispensing
spout during each rinse & self-cleaning
as well as coffee that might be spilled during brewing . So
clean and empty the drip tray everyday. 93Fill the bean
box with proper amount of fresh coffee beans, 200g at
most, and then close the bean box cover.
CAUTlON: If the grinding blade is removed, please make
sure that the grinding blade has been installed well in
position before lling the bean box with coffee beans.
Operation
This appliance is a multifunctional coffee machine, it
has the functions of “Single-cup Espresso”, “Double-
cup Espresso”, “Americano”,“Cappuccino” ,“Latte” ,“Hot
water”, “Manual froth”, “Manual clean” and “Bean-
emptying”.
SPEClAL NOTE:
The appliance will perform cleaning
automatically to make preparation for
operation when it is started each time.
NOTE:
The coffee will come out drip by drip at the
beginning (2-3 seconds after the brewing is started) and
the end (6-8 seconds before the brewing is completed)
during the brewing process, this is normal.
Power on and Preheat
1. Connect the appliance with rated voltage and press
the On/Off button at the back side of the appliance.
2. Hold and press the Power switch “ ” for at least 0.3
second and its corresponding indicator ashes, and
then the appliance enters into the self-check status.
NOTE:
Please refer to the section of
“TROUBLESHOOTlNG” to operate if there is warning
occurred.
3. Place a container under the coffee outlet.
4. The Manual clean indicator “ ” illuminates solidly
and the indicator of Power switch “ ” ashes, then the
appliance enters into the preheating stage and the auto-
clean status.
5. After the preheating of coffee boiler is completed,
the indicators of Single-cup Espresso “ ”, Double-cup
Espresso “ ”, Americano “ ” and Bean-emptying “ ”
illuminate solidly, and the appliance can be operated
normally.
6. During the preheating of steam boiler, the indicators
of Hot water “ ”, Manual froth“ ” and Manual clean “
” ash, which means the appliance can not be operated.
