Tornado TCMA-1001-GS Bruksanvisning
Tornado
kaffemaskin
TCMA-1001-GS
Les nedenfor 📖 manual på norsk for Tornado TCMA-1001-GS (47 sider) i kategorien kaffemaskin. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/47
English 1
ESPRESSO MACHINE
FULL AUTO
Milk
Frother
TCMA-1001-GS
OWNER
MANUAL
English 2
Important Safeguards
When using electrical appliances, basic precautions should
always be followed, including the following:
1. Before using check that the voltage power corresponds
to the one shown on the appliance nameplate.
2. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
3. Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and they understand the hazards involved.
4. Keep the appliance and its cord out of reach of children.
5. This appliance shall not be used by children. Children
should be supervised to ensure that they do not play with
the appliance.
6. Close supervision is necessary when any appliance is
used by or near children.
7. Cleaning and user maintenance shall not be made by
children unless they are supervised.
8. To disconnect, turn any control to “OFF”, remove plug
from wall outlet. Always hold the plug. But never pull the
cord.
9. Unplug from outlet when not in use and before cleaning.
Allow to cooling before putting on or taking off parts, and
before cleaning the appliance.
10. The use of accessory not recommended by the
appliance manufacturer may result in re, electric shock or
injury to persons.
11. Do not use outdoors.
12. Do not use appliance for other than intended use.
13. Do not let cord hang over edge of table or counter, or
touch hot surface.
14. Do not place on or near a hot gas or electric burner, or
in a heated oven.
15. Do not let the coffee machine operate without water.
16. To protect against re, electric shock and injury to
persons do not immerse cord, plug, or in water or other
liquid.
17. Do not set a hot container on a hot or cold surface.
18. The container is designed for use with this appliance. It
must never be used on a range top.
19. Do not clean container with cleansers, steel wool pads,
or other abrasive material.
20. Be careful not to get burned by the steam during the
brewing cycles.
21. Some parts of appliance are hot when operated, so do
not touch with hand. Use handles or knobs only.
22. The appliance must not be immersed.
23. This appliance is intended to be used in household and
similar applications such as:
– staff kitchen areas in shops, ofces and other working
environments;
– farm houses;
– by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments;
– indoor areas for private homes and home environments;
– the place with an altitude not higher than 2000m.
24. A warning of potential injury from misuse.
25. The heating element surface is subject to residual heat
after use.
26. The coffee-maker shall not be placed in a cabinet
when in use.
27. The operating or storage temperature of the coffee
machine should be greater than 10 degrees.
28. Switch off the appliance and disconnect from supply
before changing accessories or approaching parts that
move in use.
29. CAUTION: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out, this appliance
must not be supplied through an external switching device,
such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
30. Always disconnect the appliance from the supply if it is
left unattended and before assembling, disassembling or
cleaning.
31. Follow the instructions above, including the instructions
in the section “CLEANING AND MAINTENANCE”.
32. Save these instructions.
Know Your Coffee Machine
CONTROL PANEL
BEFORE FIRST USE
Check that all accessories are complete and the unit is
not damaged. Check and understand all the parts and
their functions. It is recommended to keep the original
packaging for future use. And then follow the operations
as below.
1. Before using for the rst use, please remove the water
tank, milk reservoir, brewer and milk frother and rinse them
with clean water.
2. Check and make sure all the removable parts are
installed well in position:
English 3
(1) Water tank:
Fill the water tank with fresh water up to Max mark and
then reassembly it into the unit and make sure it is properly
assembled, and then close the water tank lid.
(2) Milk reservoir:
1. Insert the milk tube into the hole of milk frother at the
side of coffee outlet.
2. Move the milk tube from the milk reservoir lid and then
insert it into the milk reservoir lid.
3. Install the milk reservoir and milk reservoir lid well in
position.
4. The milk tube can be removed, and please install it
rmly by yourself if it is loose.
(3) Grind setting knob
1. Turn the grind setting knob bracket counterclockwise to
the leftmost.
2. Cover the grind setting knob according to the specied
position.
3. Select the grinding setting clockwise.
NOTE: When the new coffee machine is used for the rst
time, it is suggested that the grind setting higher than
setting 8 shall be selected. The adjustable grind settings
range between 1(nest) and 15(coarsest), the number on
the grind setting knob pointed by the arrow is the actual
selected grind setting.
CAUTION: We suggest to adjust one notch at one time to
avoid the damage.
(4) Milk frother
1. Open the coffee outlet cover and make sure the milk
frother is installed well in position.
2. If the milk frotehr is installed well in position, please
close the coffee outlet cover and then insert the connecting
tube.
3. Insert the other end of the connecting tube into the milk
reservoir.
(5) Adjustment for the height of coffee outlet
1. The adjustable height of coffee outlet ranges between
85 and 115mm.
(6) Brewer
1. Open the door and check whether the brewer is installed
well in position.
(A) Check whether the arrow of the brewer is aligned with
the arrow of the upper bracket
(B) An audible click indicates that the assembling of brewer
is correct .
(C) The warning indicator “ ” will light solidly if the brewer
is not installed in place.
2. Close the door
(A) The whole door and body are on the same horizontal
plane.
(B) The warning indicator “ ” will ash if the door is not
closed properly.
(7) Inner drip tray and residue-collection container
1.Open the door and check whether the drip tray is
installed in place.
2. Open the door and check whether the residue-collection
container is installed in place.
3. The inner drip tray will not be installed well in position,
the warning indicator “ ” will ash and the machine can
not work if there is foreign object at the front of the residue-
collection container.
(8) Drip plate
1. Place the drip plate on the drip tray.
2. The drip tray must be installed well in position so that
the container can be placed on the drip plate for holding
coffee, milk or hot water.
NOTE: The drip tray collects the water from the dispensing
spout during each rinse & self-cleaning as well as coffee
that might be spilled during brewing. So clean and empty
the drip tray everyday.
(9) Fill the bean box with proper amount of fresh
coffee beans, 200g at most, and then close the bean
box cover.
CAUTION: If the grinding blade is removed, please make
sure that the grinding blade has been installed well in
position before lling the bean box with coffee beans.
OPERATION
This appliance is a multifunctional coffee machine, it
has the functions of “Single-cup Espresso”, “Double-cup
Espresso”, “Americano”,“Cappuccino” ,“Latte” ,“Hot water”,
“Manual froth”, “Manual clean” and “Bean-emptying”.
SPECIAL NOTE: The appliance will perform cleaning
automatically to make preparation for operation when it is
started each time.
NOTE: The coffee will come out drip by drip at the
beginning (2-3 seconds after the brewing is started) and
the end (6-8 seconds before the brewing is completed)
during the brewing process, this is normal.
Power on and Preheat
1. Connect the appliance with rated voltage.
2. The indicator of Power switch “ ” ashes, hold and
press the Power switch “ ” for at least 0.2 second, and
the appliance enters into the self-check status.
NOTE: Please refer to the section of
“TROUBLESHOOTING” to operate if there is warning
occurred.
3. Place a container under the coffee outlet.
4. The Manual clean indicator “ ” illuminates solidly
and the indicator of Power switch “ ” ashes, then the
appliance enters into the preheating stage and the auto-
clean status.
5. After the preheating of coffee boiler is completed,
the indicators of Single-cup Espresso “ ”, Double-cup
Espresso “ ”, Americano “ ”，Powder amount adjustment
“ ” , Coffee amount adjustment “ ” , Milk amount
adjustment “ ” and Bean-emptying “ ” illuminate solidly,
and the appliance can be operated normally.
6. During the preheating of steam boiler, the indicators of
Cappuccino “ ”, Latte “ ”, Hot water “ ”, Manual froth “
” and Manual clean “ ” ash, which means the appliance
can not be operated. After the preheating of steam boiler
is completed, the functional indicators will illuminate solidly
and the appliance can be operated normally.
7. All the functional indicators will illuminate solidly after
