CenterTrencher
RT1200TractionUnit
ModelNo.25453—SerialNo.314000001andUp
ModelNo.25453E—SerialNo.314000001andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)
*3397-318*A
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Introduction
Thisattachmentisdesignedtodigtrenchesinsoiltobury
cablingandpipingforvariousapplications.Itisnotintended
tocutrock,wood,oranyothermaterialotherthansoil.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedToroServiceDealer
orToroCustomerServiceandhavethemodelandserial
numbersofyourproductready.Figure1illustratesthe
locationofthemodelandserialnumbersontheproduct.
Writethenumbersinthespaceprovided.
Figure1
1.Locationofthemodelandserialnumberplate
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafety-alertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
©2015—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
2
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved
Contents
Safety...........................................................................3
SafetyandInstructionalDecals.................................4
Setup............................................................................5
1PreparingtoInstalltheTrencher.............................6
2InstallingtheSpeed-ShiftSwitch.............................6
3InstallingtheTrencherAttachment..........................8
4PreparingtheHydraulicMotor...............................11
5ConnectingtheLiftCylinderHoses........................12
6InstallingtheHydraulicHoses...............................13
7ConnectingtheWireHarnesstotheHydraulic
Motor...............................................................14
8PurgingAirfromtheHydraulicMotorandLift
Cylinder.............................................................15
9InstallingtheSprocket..........................................15
10InstallingtheAuger............................................16
11InstallingtheBoom............................................18
12AligningtheBoom.............................................19
13InstallingtheDiggingChain.................................21
14InstallingtheRestraintBar...................................21
Operation....................................................................22
SelectingtheProperComponentsfortheRock
Boom................................................................22
UsingtheTrencher.................................................24
OperatingTips......................................................27
Maintenance.................................................................28
GreasingtheTrencher.............................................28
GreasingtheRockBoom.........................................28
ServicingthePlanetaryDrive...................................29
ServicingtheTrencherDiggingChain.......................30
ReplacingtheDiggingChain....................................34
Storage........................................................................37
Troubleshooting...........................................................38
Safety
Improperlyusingormaintainingthisattachmentcan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandthoseinthe
tractionunit
Operator’ s Man ual
.Alwayspayattentionto
thesafetyalertsymbol,whichmeansCaution,Warning,
orDanger—personalsafetyinstruction.Failureto
complywiththeinstructionmayresultinpersonalinjury
ordeath.
WARNING
Whentheengineisoff,attachmentsintheraised
positioncangraduallylower.Someonebelow
theattachmentmaybepinnedorinjuredbythe
attachmentasitlowers.
Alwayslowertheattachmenteachtimeyoushut
offthetractionunit.
WARNING
Lightningcancausesevereinjuryordeath.
Iflightningisseenorthunderisheardinthearea,
donotoperatethemachine;seekshelter.
CAUTION
Hydraulicttings,hydrauliclines/valves,and
hydraulicuidmaybehotandcanburnyouifyou
touchthem.
Weargloveswhenmaintaininghydraulic
components.
Allowthetractionunitandtrenchertocool
beforetouchinghydrauliccomponents.
Donottouchhydraulicuidspills.
DANGER
Themovingteethandaugerwillcutorseveryour
hands,feet,orotherbodyparts.
Keephands,feet,andanyotherpartofyour
bodyorclothingawayfrommovingteeth,auger,
orotherparts.
Beforeadjusting,cleaning,repairing,or
inspectingthetrencher,lowerthetrencherto
theground,stoptheengine,waitforallmoving
partstostop,andremovethekey.
3
