FormNo.3389-753RevA
CenterlineTrencher
RT600TractionUnit
ModelNo.25431—SerialNo.313000001andUp
ModelNo.25431—SerialNo.314000001andUp
ModelNo.25431—SerialNo.315000001andUp
ModelNo.25431E—SerialNo.315000001andUp
ModelNo.25431E—SerialNo.313000001andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)
*3389-753*A
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Introduction
Thisattachmentisdesignedtodigtrenchesinsoiltobury
cablingandpipingforvariousapplications.Itisnotintended
tocutrock,wood,oranyothermaterialotherthansoil.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedToroServiceDealer
orToroCustomerServiceandhavethemodelandserial
numbersofyourproductready.Figure1illustratesthe
locationofthemodelandserialnumbersontheproduct.
Writethenumbersinthespaceprovided.
1
G023157
Figure1
1.Locationofthemodelandserialnumberplate
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
©2014—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
2
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved
Contents
Safety...........................................................................3
SafetyandInstructionalDecals.................................4
Setup............................................................................6
1InstallingtheTrencherAttachment..........................7
2PreparingtheHydraulicMotor................................8
3InstallingtheHydraulicHoses...............................10
4InstallingtheSprocket..........................................12
5InstallingtheBoom..............................................12
6AligningtheBoom...............................................14
7InstallingtheDiggingChain..................................15
Operation....................................................................16
SelectingtheProperComponentsforthe
Trencher............................................................16
UsingtheTrencher.................................................18
OperatingTips......................................................20
Maintenance.................................................................21
GreasingtheTrencher(LeftSide).............................21
GreasingtheTrencher(RightSide)............................21
ServicingthePlanetaryDrive...................................22
ServicingtheTrencherDiggingChain.......................23
ReplacingtheDiggingChain....................................27
Storage........................................................................29
Troubleshooting...........................................................30
Safety
Improperlyusingormaintainingthetrenchercanresult
ininjury.Toreducethepotentialforinjury,comply
withthesesafetyinstructionsandthoseinthetraction
unit
Operator’ s Man ual
.Alwayspayattentiontothe
safetyalertsymbol,whichmeansCaution,Warning,or
Danger—personalsafetyinstruction.Failuretocomply
withtheinstructionmayresultinpersonalinjuryor
death.
DANGER
Theremaybeburiedpower,gas,and/ortelephone
linesintheworkarea.Anelectricshockoran
explosionmayoccurifyoudigintoautilityline.
Havethepropertyorworkareamarkedforburied
linesanddonotdiginmarkedareas.Contactyour
localmarkingserviceorutilitycompanytohavethe
propertymarked(forexample,intheUnitedStates,
call811forthenationwidemarkingservice).
DANGER
Themovingteethandaugerwillcutorseveryour
hands,feet,orotherbodyparts.
Keephands,feet,andanyotherpartofyour
bodyorclothingawayfrommovingteeth,auger,
orotherparts.
Beforeadjusting,cleaning,repairing,or
inspectingthetrencher,lowerthetrencherto
theground,stoptheengine,waitforallmoving
partstostop,andremovethekey.
WARNING
Whentheengineisoff,anattachmentintheraised
positioncangraduallylower.Someonebelow
theattachmentmaybepinnedorinjuredbythe
attachmentasitlowers.
Alwayslowertheattachmenteachtimeyoushut
offthetractionunit.
WARNING
Whengoingupordownhill,themachinecould
overturniftheheavyendistowardthedownhill
side.Someonemaybepinnedorseriouslyinjured
bythemachineifitoverturns.
Operatethemachineupanddownslopeswith
theheavyendofthemachineuphill.Anattached
trencherwillmakethebackendofthemachine
heavy.
3
