Side 1/17

Typical Network

Note

The typical connection for TL-WA7510N is shown as above. Please make

sure that the two CPEs are placed face to face; otherwise the wireless

signal strength might be weak. Here shows several incorrect examples.

TL-WA7510N is used for remote point-to-point connection. It makes remote

Internet share possible.

Note

If you are using an external ant . enna to connect, please refer to Appendix 1

Installation

Installation Installation

Locate a suitable mounting site for your CPE. For choosing the best location,

select an elevated location where trees, buildings and large steel structures will

not obstruct the antenna signals and which offers maximum line-of-sight

propagation with the users.

Connect one end of an Ethernet cable to the POE port of the provided Power

Injector and the other end of the Ethernet cable to the LAN port of the CPE.

Then, connect the LAN port of

the Power Injector to a PC using

another Ethernet cable. Finally,

plug the provided power adapter

into the DC jack on the Power

Injector, and the other end to a

standard electrical wall socket.

Note

Please use only wired network connections to configure the AP.

djust the direction of your CPE for the best signal. Place the straps through

the slots on the back of the CPE and then around the

ole. Ti

hten the stra

Connecting the Device

The connection will be similar to the figure below after the above steps are

finished.

Turn on all your network devices and then check to see if the LEDs on the AP

display normally as the diagram below describes.

Note

If the LEDs display abnormally, please check to see if all the cable

connectors (power adapter and Ethernet cable) are well connected to your

devices.

Solid light

Solid light or flashing

If you use two CPEs to build

the network, please make

sure that the two CPEs are

placed face to face.

Solid light

Produkspesifikasjoner

Merke:	TP Link
Kategori:	Tilgangspunkt
Modell:	TL-WA7510N
LED-indikatorer:	Ja
Sertifisering:	CE, FCC, RoHS
Kablingsteknologi:	10/100BASE-T(X)
Nettverksstandard:	IEEE 802.11a, IEEE 802.11n
Kompatible operativsystemer:	Windows 2000, XP, Vista, 7\nMAC\nNetWare\nUNIX\nLinux
MAC-adressefiltrering:	Ja
Maksimal dataoverføringshastighet:	150 Mbit/s
Dimensjoner (B x D x H):	250 x 85 x 60.5 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-30 - 70 °C
Oppbevaringstemperaturomåde (Celsius):	5 - 95 °C
Lagringsrelativ fuktighet:	-40 - 70
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Sikkerhetsalgoritmer:	128-bit WEP, 152-bit WEP, SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
Trådløse teknologier:	802.11a/n
Relativ luftfuktighet under drift (H-H):	10 - 90
Nettverksgrensesnitt:	Raskt Ethernet
Intern:	Nei
AC-adapter bunt:	Ja
Strøm over Ethernet (PoE):	Ja
Antenne forbedringsnivå (max):	15 dBi
Frekvensbånd og driftskanaler:	5.745 - 5.825 GHz
Mottakersensitivitet:	802.11a 54M: -77dBm 48M: -79dBm 36M: -83dBm 24M: -86dBm 18M:-91dBm 12M:-92dBm 9M:-93dBm 6M:-94dBm\n802.11n 150M: -73dBm 121.5M: -76dBm 108M: -77dBm 81M: -81dBm 54M:-84dBm 40.5M:-88dBm 27M:-91dBm 13.5M:-93dBm
