Side 1/4

Owner's Manual

4POSTRAILKIT1U

Adjustable Rackmount Shelf Kit

Important Safety Instructions

Español / Français : 3

Installation

1111 W. 35th St., Chicago, IL 60609 USA

www.tripplite.com/support

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that must be followed during the installation and operation of the product described in this manual.

Failure to comply may invalidate the warranty and cause property damage or personal injury.

• Use the included shelves and mounting hardware to mount your rackmount equipment in a 4-post rack or rack enclosure. If you need to install your

equipment in a 2-post rack, order Tripp Lite’s 2-Post Rackmount Kit (model: 2POSTRMKITWM).

• The instructions in this manual are for common rack and rack enclosure types and may not be appropriate for all mounting applications. You must

determine the fitness of hardware and procedures before mounting. If hardware or procedures are not suitable for your application, contact the

manufacturer of your rack or rack enclosure for a solution.

• Rackmount equipment may be extremely heavy—be careful when moving or lifting equipment. Use one or more assistants if necessary.

Square-Hole Rack Installation

Secure the shelves

to the mounting rails permanently using the

included screws and cup washers

as shown.

Tighten all screws before proceeding.

Warning: Do not attempt to install your equipment until you

have inserted and tightened the required screws.

WARRANTY

REGISTRATION

chance to win a FREE Tripp Lite

product www.tripplite.com/warranty

With the aid of an assistant (if necessary), lift your equipment and slide

it into the shelves. Attach the equipment mounting brackets to the

forward mounting rails with user-supplied screws and washers. Tighten

all screws securely.

201204261 93-3215.indb 1 6/6/2012 10:48:08 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	4POSTRAILKITWM
Vekt:	1180 g
Bredde:	37.8 mm
Dybde:	381 mm
Høyde:	43.7 mm
Opprinnelsesland:	China
Pakkevekt:	1360 g
Kompatibel stativbredde:	19 "
Produktfarge:	Sølv
Pakkedybde:	385.1 mm
Pakkehøyde:	50 mm
Pakkebredde:	54.9 mm
Harmonisert system (HS)-kode:	7326.90.8688
Modell/Type:	Montering Sett
Kroppsmateriale:	Stål
Skruer inkludert:	Ja
Rack-kapasitet:	1U
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332206371
Masterkassens (ytterkassens) bruttovekt:	13970 g
Masterkassens (ytterkassens) lengde:	405.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	270 mm
Masterkassens (ytterkassens) høyde:	130 mm
