Owner’s Manual

Purchased product

may differ from image.

Models:

NPOE-30W-1G

NPOE-30W-1G-INT

1-Port Gigabit High-Power

PoE+ Midspan Injector

Español 5

Français 9

Deutsch 13

Italiano 17

Package Contents

• Gigabit High-Power PoE+ Injector

• External Power Supply

- NPOE-30W-1G: C5 to NEMA 5-15P Power Cable - 2 ft.

- NPOE-30W-1G-INT: C5 to CEE 7/16 Schuko (Europe) and C5 to

BS 1363 (UK)

• Owner’s Manual

Installation

1. Using existing or newly run Cat5e/6 cable, connect a LAN port on a

non-PoE switch or network jack to the LAN port on the injector.

2. Connect any IEEE 802.3af/at-compliant PoE device to the POE port on

the injector.

3. Use the included power cable (and compatible plug, if applicable) to

connect the injector to an AC outlet.

Product Features

• Save time and money by delivering up to 10/100/1000 Mbps of data

and up to 30W of power via existing network cables.

• Supports distances up to 328 ft. (100 m).

• Supports all IEEE 802.3at- and IEEE 802.3af-compliant PoE devices

(Wireless LAN access points and bridges, VoIP, IP surveillance cameras,

etc.).

• Supports IEEE 802.3at/af detection and short-circuit, overload and

high-voltage protection.

• Simpleplug-and-playdesignwithnocongurationrequired.

• Fanless design ideal for silent operation.

• Flexible design allows for either desktop or surface-mount use.

Specications

IEEE Standards IEEE 802.3af (Power over Ethernet)

IEEE 802.3at (High-Power PoE+ Power over Ethernet)

IEEE 802.3 (10Base-T Ethernet)

IEEE 802.3ab (Gigabit Ethernet)

IEEE 802.3u (100Base-TX Fast Ethernet)

IEEE 802.3x (Flow control, for full duplex mode)

Media Support 100Base-TX Cat5 UTP/STP RJ45, 8 pin

1000Base-T Cat5e/6 UTP/STP RJ45, 8 pin

Ports One RJ45 10/100/1000 Mbps Input port

One RJ45 10/100/1000 Mbps Data + Power Output port

Protection Functions Short circuit protection for short GND

Overload protections for currents over 0.6A

PoE Pinout IEEE 802.3af/at Standard Mode B

Pin 4: DC (+)

Pin 5: DC (+)

Pin 7: DC (-)

Power Input: 100-240V AC, 50/60 Hz

Max Power Consumption: 35W

LED Power (Green), Active (Green)

Environmental Operating Temperature: 32° F to 104° F (0° C to 40° C)

Storage Temperature: -4° F to 176° F (-20° to 80° C)

Operating Humidity: 5% to 90% RH, Non-Condensing

Dimensions [H x W

x L]

1.4 x 2.6 x 5.4 in. (36 x 66 x 137 mm)

Weight 0.44 lb. (0.2 kg)
