Side 1/32

In-Line Network

Surge Protector,

10 Gbps, Cat6a

Model: B110-SP-10G

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Quick Start Guide

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 9 • Français 17 • Русский 25

• B110-SP-10G 10 Gbps In-Line Network Surge Protector

• Grounding Wire

• Mounting Screws (x4)

• Screw Anchors (x4)

• Grounding Wire Screw

• Quick Start Guide

• Protects your network equipment’s inputs and outputs against electro-

static discharge (ESD), power surges and cable discharge events

• Meets the following IEC regulations:

IEC 61000-4-2: Indirect discharge (4kV), direct discharge (8kV)

IEC 61000-4-5 (Lightning) 2kA (8/20µs), 1kV (8/20µs)

• Easy to connect between network source and device using

standard Cat5/5e/6/6a/8 cabling

• Rapid reaction time under 1 ns helps prevent damage from

lightning/power surges

• Supports Ethernet network data transmission speeds up to 10 Gbps

• Plug-and-play operation with no software required for easy,

immediate installation

• Supports distance between the B110-SP-10G and equipment up

to 330 ft. (100 m)

• Compliant with the Federal Trade Agreements Act (TAA) for GSA

(General Services Administration) Schedule and other federal

procurement contracts

Package Includes

Product Features

Note: The following instructions assume that two network devices are

currently connected together.

Single Device Protection:

1. Disconnect the installed patch cable from the device you wish

to protect and attach it to the “Cable End” of the In-Line 10G

Network Surge Protector.

2. With a user-supplied Cat5/5e/6/6a/8 patch cable, connect the

device to be protected to the “Equipment End” of the In-Line

10G Network Surge Protector.

Note: For best protection performance, the patch cable between

the “Equipment End” on the B110-SP-10G and the equipment

to be protected should not exceed 330 ft. (100 m). Tripp Lite’s

N261-Series Cat6a Snagless Patch Cables are recommended.

3. Connect the ground wire to the In-Line 10G Network Surge

Protector and then to earth ground.

Installation

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	B110-SP-10G
Vekt:	250 g
Bredde:	64.3 mm
Dybde:	25.7 mm
Høyde:	91.7 mm
Opprinnelsesland:	Taiwan
Pakkevekt:	560 g
Sertifisering:	IEC 61000, RoHS; CE (Europe); REACH; FCC (USA)
Materiale:	Aluminium
Dataoverføringshastighet:	10 Gbit/s
Kabellengde:	- m
Produktfarge:	Sort
Pakkedybde:	164 mm
Pakkehøyde:	55 mm
Pakkebredde:	214 mm
Pakketype:	Boks
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 80
Bærekraftsertifikater:	CE, Federal Communications Commission (FCC), REACH, RoHS
Harmonisert system (HS)-kode:	8525.50.3035
Relativ luftfuktighet under drift (H-H):	0 - 80
Antall AC outlets:	0 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	5900 g
Masterkassens (ytterkassens) lengde:	227 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	175 mm
Nominell innputspenning:	- V
Strømstøt energivurdering:	- J
