DVI Dual Link Active Extender

Model:

B120-000

Package Contents:

• B120-000DVIDualLinkActiveExtender

• ExternalPowerSupply 

(Input:100-240V,50/60Hz,0.5AOutput:5V,2A)

• ScrewdriverforEqualizationadjustment

• Owner’sManual

Installation

Note: Test to make sure the entire installation works properly before pulling cables through ceilings/walls.

 ConnectthelongerDVI-DDualLinkcablebetweenthesourceandtheconnectorontheB120-000labeled“Source.”

Note: For extension distances over 75 ft., use 24Awg DVI Dual Link cable.

 ConnecttheexternalpowersupplytotheB120-000,andthenplugitintoaTrippLiteSurgeSuppressor,UninterruptiblePowerSupply(UPS),

orPowerDistributionUnit(PDU).TheGreenLEDwillilluminatetoindicatethattheunitisreceivingpower.

 ConnecttheshorterDVI-DDualLinkcablebetweenthemonitorandtheconnectorontheB120-000labeled“Display.”TheOrangeLEDwill

illuminatetoindicatethatthereisanactivesignalbetweenthesourceandthemonitor.

Note: The DVI-D Dual Link cable connecting the monitor to the B120-000 must be no longer than 16 ft. (5 m.).

 Ifnecessary,usetheequalizationcontroltoadjustthevideoimage.

Note: An improper Equalization setting can result in no image being displayed at all. If no image is displayed on your monitor, try adjusting the equalization until

an acceptable imaged is displayed.

Product Features:

• Supportsamaximumvideoresolutionof2560x1600@60Hz

• ExtendsaDVI-Dsignalupto150ft.fromthesource

• Built-inEqualizationcontroltoadjustthevideoimage

• HDCP-compliant

COMPUTER

MONITOR

B120-000

1111W.35thStreet,Chicago,IL60609USA

www.tripplite.com/support

Warranty

Registration:

chancetowinaFREETrippLite

product—www.tripplite.com/warranty

Owner’s Manual

201203199 93-3127.indd 1 3/26/2012 2:24:27 PM

Warranty & Warranty Registration
