Side 1/12
HDMI Over Cat6 Pigtail
Extender Kits and Receiver
with Repeater, 4K/60 Hz
Extender Kit: B127U-111-PHPH
2-Port Splitter Kit: B127U-002-PHPH2
Receiver with Repeater: B127U-110-PH
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2023 Tripp Lite. All rights reserved.
Owner's Manual
Este manual está disponible en español en la página de Tripp Lite: tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar:
tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
2
B127U-111-PHPH
• HDMI over Cat6 Pigtail Transmitter and Receiver with
Repeater Kit
• Extends a 4K x 2K (3840 x 2160) @ 60 Hz A/V signal up to
230 ft. (70 m) from the source over 24 AWG Cat6 cabling
• Transmitter and receiver units can be powered by the built-
in 1 ft. USB-A cables for connecting to the USB port on a
display or to a USB power adapter, or by the Micro-USB
ports on each unit
• 1 ft. HDMI connectors on transmitter and receiver units
connect to the source and display
• View the transmitted video content on a local display via the
4K/60 Hz HDMI port on the transmitter unit
• Compatible with DisplayPort (B127U-110-PD) and HDMI
(B127U-110-PH) receivers to create exible daisychain
installations with multiple video outputs
• Daisychainable up to 4 layers, with each additional
B127U-110-PH receiver unit (sold separately) providing an
additional 230 ft., up to a total of 920 ft. (280 m)
• Supports passthrough audio formats up to 7.1-channel
surround sound
• Real-time video compression and decompression technology
• Compatible with HDCP 2.2 and 1.4 and High Dynamic
Range (HDR)
Product Features
3
Product Features
B127U-002-PHPH2
• 2-Port HDMI over Cat6 Pigtail Splitter and Receivers Kit
• Extends a 4K x 2K (3840 x 2160) @ 60 Hz A/V signal to two
displays up to 230 ft. (70 m) from the source over 24 AWG
Cat6 cabling
• Transmitter and receiver units are powered by built-in 1 ft.
USB-A cables for connecting to the USB port on a display or
to a USB power adapter
• Multi-Resolution technology allows the receivers to connect
to any 1080p, 4K/30 Hz or 4K/60 Hz display without aecting
the resolution of the other displays connected to the splitter
• Optionally, power transmitter and receiver units via Micro-
USB ports on each unit
• 1 ft. HDMI connectors on transmitter and receiver units
connect to the source and display
• Supports passthrough audio formats up to 7.1-channel
surround sound
• Real-time video compression and decompression technology
• Compatible with HDCP 2.2 and 1.4 and High Dynamic
Range (HDR)
• Compatible with DisplayPort (B127U-110-PD) and HDMI
(B127U-110-PH) receivers to create exible daisychain
installations with multiple video outputs. Each port on the
splitter can extend up to four connected receivers, for a total
of eight receivers and 920 ft. (280 m) per daisychain (sold
separately).
