Side 1/28

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

HDMI over Cat5 Extenders

and Extender/Splitters

Extender Kit Model: B126-1A1 and B126-1A1-WP

Local Unit Models: B126-002 and B126-004

Remote Unit Models: B126-1P0, B126-1P0-WP-1,

B126-1A0, B126-1A0-WP-1 and B126-110

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Package Contents 2

Product Features 2

Mounting Instructions 7

Standard Extender Kit Installation 8

Extender Kit with Remote/Repeater Installation 10

Standard Extender/Splitter Installation 13

Extender/Splitter with Remote/Repeater Installation 16

Extender/Splitter Daisy-Chain Installation (B126-004 only) 20

Extender/Splitter Daisy-Chain with Remote/Repeater 23

Installation (B126-004 only)

Warranty & Warranty Registration 27

201109206-93-3023-EN.indd 1 10/24/2011 10:01:17 AM

Package Contents

Product Features

B126-1A1

B126-1A1-WP

B126-002

B126-004

B126-1A0

B126-1A0-WP-1

B126-1P0

B126-1P0-WP-1

B126-110

Local Unit (L), Remote Unit (R),

or Both (B)

B B L L R R R R R

External Power Supplies

(0, 1, or 2)

2 2 1 1 1 1 0 0 1

Mounting Hardware X X X X X

Wallplate Screws X X X

Screwdriver for

Equalization Adjustment

X X X X X

HDMI Daisy-chain Cable X

All

• Supportamaximumvideoresolutionof1080p(60Hz)

• Plug-and-play;nosoftwareordriversrequired

• Supportupto7.1channelsurroundsoundaudio

• HDCPand3Dcompatible

201109206-93-3023-EN.indd 2 10/24/2011 10:01:17 AM

Product Features

B126-1A1

• HDMIoverCat5ActiveExtenderKit(Box-style)

• Extendsa1080i(60Hz)signalupto200ft.fromthesource,ora

1080p(60Hz)signalupto150ft.fromthesource

• FeaturesanadditionalHDMIportonthelocaltransmitterunitforthe

connection of local monitor

• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo

image adjustment

• Includesmountinghardwarethatallowsboththelocaltransmitter

and remote receiver units to be wallmounted, rackmounted or pole

mounted

B126-1A1-WP

• HDMIoverCat5ActiveExtenderWallplateKit

• Extendsa1080i(60Hz)signalupto200ft.fromthesource,ora

1080p(60Hz)signalupto150ft.fromthesource

• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo

image adjustment

• RJ45-stylewallplatesallowfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

B126-002

• 2-PortHDMIoverCat5Extender/SplitterLocalTransmitterUnit

(Box-style)

• SplitsanHDMIsignalinto2

• Workswithremote/repeaterandreceiverunitstoextendanHDMI

signalpastthe16ft.(5m)distancelimitation

• Includesmountinghardwarethatallowsunittobewallmounted,

rackmounted or pole mounted

201109206-93-3023-EN.indd 3 10/24/2011 10:01:17 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	AV ekstender
Modell:	B126-110-INT
Vekt:	680 g
LED-indikatorer:	Ja
Maksimal oppløsning:	- piksler
Dimensjoner (B x D x H):	114.3 x 63.5 x 25.4 mm
Antall HDMI-utganger:	1
Produktfarge:	Sort
Støttede grafikkoppløsninger:	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1440 x 900 (WXGA+)
Støttede videofunksjoner:	480i, 480p, 720p, 1080i, 1080p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Modell/Type:	AV-forsterker
RJ-45-inngangsporter:	1
DC-inngangskontakt:	Ja
Lydsystem:	Flerkanal
Lyd-utgang kanaler:	7.1 kanaler
Antall:	1
Maksimal overføring avstand:	53.34 m
Kabeltyper som støttes:	Cat5e, Cat6
RJ-45-utgangsporter:	1
