Side 1/84

Owner’s Manual

HDMI over Cat5 Extenders

and Extender/Splitters

Extender Kit Models: B126-1A1 and B126-1A1-WP

Local Unit Models: B126-002 and B126-004

Remote Unit Models: B126-1P0, B126-1P0-MINI,

B126-1P0-WP-1, B126-1A0, B126-1A0-WP-1 and B126-110

Español 29 • Français 57

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

17-07-081-933731.indb 1 8/2/2017 8:57:20 AM

Package Contents

Product Features

B126-1A1

B126-1A1-WP

B126-002

B126-004

B126-1A0

B126-1A0-WP-1

B126-1P0

B126-1P0-MINI

B126-1P0-WP-1

B126-110

Local Unit (L), Remote Unit (R)

or Both (B)

B B L L R R R R R R

External Power Supplies

(0, 1 or 2)

2 2 1 1 1 1 0 0 0 1

Mounting Hardware X X X X X

Wall Plate Screws X X X

Screwdriver for

Equalization Adjustment

X X X X X

HDMI Daisy-Chain Cable X

USB Micro-B Cable X

All

• Support a maximum video resolution of 1080p (60 Hz)

• Plug and play—no software or drivers required

• Support up to 7.1-channel surround sound audio

• HDCP and 3D compatible

17-07-081-933731.indb 2 8/2/2017 8:57:20 AM

Product Features

B126-1A1

• HDMI over Cat5 Active Extender Kit

• Extends a 1080i (60 Hz) signal up to 200 ft. from the source, or a

1080p (60 Hz) signal up to 150 ft. from the source

• Additional HDMI port on the local transmitter unit allows connection of

local monitor

• Remote receiver unit features a built-in equalization control for video

image adjustment

• Includes mounting hardware that allows both the local transmitter

and remote receiver units to be wall-mounted, rack-mounted or

pole-mounted

B126-1A1-WP

• HDMI over Cat5 Active Extender Wall Plate Kit

• Extends a 1080i (60 Hz) signal up to 200 ft. from the source, or a

1080p (60 Hz) signal up to 150 ft. from the source

• Remote receiver unit features a built-in equalization control for video

image adjustment

• RJ45-style wall plates allow for the use of standard Cat5e/6 patch cables;

110 punchdown connection not required

B126-002

• 2-Port HDMI over Cat5 Extender/Splitter Local Transmitter Unit

• Splits an HDMI signal into two

• Works with remote/repeater and receiver units to extend an HDMI signal

past the 16 ft. (5 m) distance limitation

• Includes mounting hardware that allows unit to be wall-mounted,

rack-mounted or pole-mounted

17-07-081-933731.indb 3 8/2/2017 8:57:20 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	AV ekstender
Modell:	B126-1A1
LED-indikatorer:	Ja
Opprinnelsesland:	Taiwan
Pakkevekt:	770 g
Full HD:	Ja
HDCP:	Ja
3D:	Ja
Utgangsstrøm:	5 V
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Støttede lydkanaler:	7.1
Antall videoporter:	3
Produktfarge:	Sort
Pakkedybde:	210.8 mm
Pakkehøyde:	55.9 mm
Pakkebredde:	157.5 mm
Støttede videofunksjoner:	1080i, 1080p
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Harmonisert system (HS)-kode:	8525.50.3035
Video ut:	HDMI
Relativ luftfuktighet under drift (H-H):	20 - 90
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332158922
Masterkassens (ytterkassens) bruttovekt:	8030 g
Masterkassens (ytterkassens) lengde:	574 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	231.1 mm
Masterkassens (ytterkassens) høyde:	175.3 mm
Innput-strøm:	0.5 A
Kabeltyper som støttes:	Cat5e, Cat6
Video tilkoblingstype:	HDMI
Emballasjelengde:	210.8 mm
