Side 1/52

Owner’s Manual

4K/60 DisplayPort over Cat6

Extenders and Splitters

Extender Kit Model: B127-1A1-DH

Splitter Kit Models: B127-002-D2H, B127-004-D4H

Local Transmitter Model: B127-008-D

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

surge protector in our monthly drawing!

tripplite.com/warranty

Español 13 • Français 26 • Русский 39

Package Contents

B127-1A1-DH

B127-002-D2H

B127-004-D4H

B127-008-D

Local Unit (L), Remote Unit (R) or Both (B) B B B L

External Power Supply (Input: 100V-240V) 1 1 1 1

International Plug Adapters

(North America, U.K., Europe, Australia)

Y Y Y Y

Mounting Hardware Y Y Y Y

Product Features

All

• Support 4K video resolution (3840 x 2160 @ 60 Hz) and 4:4:4

chroma subsampling

• Support up to 7.1-channel surround sound audio

• DisplayPort 1.2a compatible

• Supports up to 8-channel LPCM, AC-3, DTS digital audio

• Plug and play—no software or drivers required

B127-1A1-DH

• DisplayPort over Cat6 Power-over-Cable (PoC) Extender Kit

• Extends a 4K (3840 x 2160 @ 60 Hz) signal up to 125 ft. (38 m)

from the source

• Additional HDMI port on the local transmitter unit allows connection of

a local monitor

• Remote receiver unit features built-in equalization (EQ) control and

auto EDID image adjustment

•

Includes mounting hardware that allows both the local transmitter and

remote receiver units to be wall-mounted, rack-mounted or pole-mounted

B127-002-D2H

• DisplayPort over Cat6 Power Over Cable (PoC) 2 Port Splitter/Extender

Kit

• Extends a 4K (3840 x 2160 @ 60 Hz) signal up to 125 ft. (38 m)

from the source

• Remote HDMI receiver units feature built-in equalization (EQ) control

and auto EDID image adjustment

• Kit includes a 2-port splitter extender and two remote receivers

• Includes mounting hardware that allows unit to be wall-mounted, rack-

mounted or pole-mounted

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	B127-004-D4H
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	2220 g
Sertifisering:	CE, FCC, REACH
HDCP:	Ja
Materiale:	Metall
HDMI-versjon:	2.0
DisplayPorts inn:	1
Utgangsstrøm:	2 A
HDMI inn:	1
HDCP-versjon:	2.2
Antall HDMI-utganger:	1
Driftsspenning:	24 V
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Pakkedybde:	342.9 mm
Pakkehøyde:	104.1 mm
Monteringssett:	Ja
Pakkebredde:	154.9 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	4
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Lyd-utgang kanaler:	7.1 kanaler
AC-adapter bunt:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332239034
Masterkassens (ytterkassens) bruttovekt:	11520 g
Masterkassens (ytterkassens) lengde:	579.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	378.5 mm
Masterkassens (ytterkassens) høyde:	180.3 mm
Innput-strøm:	1.5 A
Maksimal overføring avstand:	38 m
Kabeltyper som støttes:	Cat6
RJ-45-utgangsporter:	1
Extended display identification data (EDID):	Ja
