Owner’s Manual

4K/60 HDMI over Cat6 Extenders

and Extender/Splitters

Extender Kit Models: B127-1A1-HH, B127-002-2H2

and B127-004-H4H

Local Unit Models: B127-002-H, B127-004-H

Remote Unit Models: B127-100-H, B127-100-H-SR

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

Español 17 • Français 33 • Русский 49

19-01-427-933919.indb 1 3/18/2019 4:56:29 PM

Package Contents

Product Features

B127-1A1-HH

B127-002-2H2

B127-004-H4H

B127-002-H

B127-004-H

B127-100-H

B127-100-H-SR

Local Unit (L), Remote Unit (R)

or Both (B)

B B B L L R R

External Power Supplies

(0 or 1)

1 1 1 1 1 0 0

Mounting Hardware Y Y Y Y Y Y N

All

• Support a maximum video resolution of 4K (3840 x 2160) @

60 Hz with 4:4:4 Chroma Subsampling

• Support up to 7.1-channel surround sound audio

• HDMI 2.0, HDCP 2.2 and HDR compatible

• Plug and play—no software or drivers required

B127-1A1-HH

• HDMI over Cat6 Power-over-Cable (PoC) Extender Kit

• Extends a 4K (3840 x 2160) @ 60 Hz signal up to 125 ft. (38 m)

from the source

19-01-427-933919.indb 2 3/18/2019 4:56:29 PM

Product Features

• Additional HDMI port on the local transmitter unit allows connection of

local monitor

• Remote receiver unit features built-in equalization (EQ) control and

auto EDID image adjustment

• Includes mounting hardware that allows both the local transmitter and

remote receiver units to be wall-mounted, rack-mounted or pole-

mounted

B127-002-2H2

• HDMI over Cat6 Power-over-Cable (PoC) 2-Port Splitter/Extender Kit

• Extends a 4K (3840 x 2160) @ 60 Hz signal up to 125 ft. (38 m)

from the source

• Remote receiver unit features built-in equalization (EQ) control and

auto EDID image adjustment

• Kit includes a 2-Port Splitter Extender and two Remove Receivers

• Includes mounting hardware that allows unit to be wall-mounted,

rack-mounted or pole-mounted

B127-004-H4H

• HDMI over Cat6 Power-over-Cable (PoC) 4-Port Splitter/Extender Kit

• Extends a 4K (3840 x 2160) @ 60 Hz signal up to 125 ft. (38 m)

from the source

• Remote receiver unit features built-in equalization (EQ) control and

auto EDID image adjustment

• Kit includes a 4-Port Splitter Extender and four Remote Receivers

• Includes mounting hardware that allows unit to be wall-mounted,

rack-mounted or pole-mounted

• Additional HDMI port on the local transmitter unit allows connection of

local monitor

19-01-427-933919.indb 3 3/18/2019 4:56:29 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	B127-004-H
Vekt:	290 g
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	1130 g
Sertifisering:	CE, FCC, REACH
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
Materiale:	Metall
HDMI-versjon:	2.0
Fargedybde:	24 bit
Utgangsstrøm:	2 A
HDMI inn:	2
HDCP-versjon:	2.2
Driftsspenning:	24 V
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Pakkedybde:	345.4 mm
Pakkehøyde:	61 mm
Monteringssett:	Ja
Pakkebredde:	160 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender
Ekstern strømadapter:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Lyd-utgang kanaler:	7.1 kanaler
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332239041
Masterkassens (ytterkassens) bruttovekt:	11430 g
Masterkassens (ytterkassens) lengde:	586.7 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	375.9 mm
Masterkassens (ytterkassens) høyde:	200.7 mm
Innput-strøm:	1.5 A
Maksimal overføring avstand:	38 m
Kabeltyper som støttes:	Cat6
RJ-45-utgangsporter:	4
Extended display identification data (EDID):	Ja
