Side 1/20

WARRANTY REGISTRATION

win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

DisplayPort over Cat6 4K Extender

Kits and Receiver with Repeater

DisplayPort over Cat6 Extender Kit: B127A-1A1-BDBD

DisplayPort to HDMI over Cat6 Extender Kit: B127A-1A1-BDBH

DisplayPort over Cat6 Receiver with Repeater: B127A-110-BD

DisplayPort over Cat6 Transmitter with Repeater Extender Kit:

B127A-111-BDTD

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

Este manual está disponible en español en la página de Tripp Lite:

tripplite.com

Ce manuel est disponible en français sur le site Web de Tripp Lite :

tripplite.com

Русскоязычная версия настоящего руководства представлена на

веб-сайте компании Tripp Lite по адресу: tripplite.com

Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website

verfügbar: tripplite.com

Package Contents

Optional Accessories

Product Features

B127A-1A1-BDBH

• DisplayPort 1.2a to HDMI over Cat6 Power over Cable (PoC) Extender

Kit

• Extends a 4K x 2K (3840 x 2160) @ 60 Hz signal, as speciﬁed in

HDMI 2.0, up to 230 ft. (70 m) from the source.

• Built-in local HDMI port supports 4K @ 60 Hz signal

• Real-time video compression and decompression technology

• Supports up to 7.1-channel surround sound audio

• Transmitter

• Receiver

• External Power Supply (Input: 100-240V, 50/60 Hz, 0.6A;

Output: 24V 1A)

• (4x) International Plugs*

• Mounting Hardware

• Owner's Manual

*Includes NEMA 1-15P (North America), CEE 7/16 Schuko (Europe), BS 1363 (U.K.) and AS/NZS 3112 (Australia)

plugs

• N202-Series Cat6 24 AWG Solid-Wire Patch Cables

• P569-XXX-CERT or P568-XXX-2A Series High-Speed HDMI Cables

• P580-Series DisplayPort Cables with Latches

• B127A-010-H Signal Booster

Product Features

• Receiver features built-in Toslink port for audio extraction function

• Compatible with B127A-010-H signal booster (sold separately) to

increase transmission distance up to 400 ft. from the source

• HDCP 2.2 compatible

• Plug-and-play - no software or drivers required

• Supports bi-directional IR and USB 1.1 function by DIP switch selection

• Includes mounting hardware that enables both the local transmitter

and remote receiver units to be wall-mounted, rack-mounted or pole-

mounted

B127A-1A1-BDBD

• DisplayPort 1.2a over Cat6 extender and receiver kit with Power over

Cable (PoC)

• Extends a 4K x 2K (3840 x 2160) @ 30 Hz signal up to 230 ft. (70 m)

from the source

• Built-in local HDMI port supports 4K x 2K (3840 x 2160) @ 30 Hz

resolutions

• Real-time video compression and decompression technology

• Supports up to 7.1-channel surround sound audio

• Compatible with B127A-010-H signal booster (sold separately) to

increase transmission distance up to 400 ft. from the source

• Receiver features a Toslink port for audio extraction

• Supports DisplayPort 1.2a and is HDCP 2.2 compatible

• Plug-and-play - no software or drivers required

• Supports bi-directional IR and USB 1.1 function by DIP switch selection

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	AV ekstender
Modell:	B127A-1A1-BDBH
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-kontakttype:	Micro-USB, USB Type-A
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	660 g
Sertifisering:	TAA
HDCP:	Ja
USB-versjon:	1.1
Maksimal oppdateringshastighet:	60 Hz
3D:	Ja
Materiale:	Metall
HDMI-versjon:	2.0
Fargedybde:	36 bit
DisplayPorts inn:	1
Utgangsstrøm:	1 A
HDMI inn:	1
HDCP-versjon:	1.4/2.2
Antall HDMI-utganger:	1
Driftsspenning:	24 V
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50-60 Hz
Mottakervekt:	453.6 g
Kabellengde:	1.38 m
Produktfarge:	Sort
Antall USB-porter:	3
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Monteringssett:	Ja
Pakkebredde:	260.1 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	CE, REACH, RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
DC-inngangskontakt:	Ja
Kan monteres på vegg:	Ja
Lydsystem:	Flerkanal
Inkluderte kraftpluggtyper:	AU, EU, NA, UK
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Lyd-utgang kanaler:	7.1 kanaler
Fjern (IR)-utgang:	2
AC-adapter bunt:	Ja
Bærekraftsamsvar:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332258653
Masterkassens (ytterkassens) bruttovekt:	6900 g
Masterkassens (ytterkassens) lengde:	273 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	175 mm
Innput-strøm:	0.6 A
Optisk digital lydutgang:	1
Fjerninngang (IR):	2
Maksimal overføring avstand:	70.1 m
Kabeltyper som støttes:	Cat5, Cat5e, Cat6, HDMI
Trådløs mottaker (B x D x H):	115 x 62.4 x 27 mm
Senderdimensjoner (BxDxH):	115 x 62.4 x 27 mm
Sendervekt:	453.6 g
RJ-45-utgangsporter:	1
Consumer Electronics Control (CEC)-støtte:	Ja
Extended display identification data (EDID):	Ja
