Side 1/80

HDMI over Cat6 Extenders for

Medical Applications

Extender Kit Model: B127M-101-H

Receiver Model: B127M-100-H

Splitter Model: B127M-004-H

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

WARRANTY REGISTRATION

win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 17 • Français 33 • Русский 49 • Deutsch 65

Package Contents

B127M-004-H Splitter Unit

• External Power Supply (Input: 100-240V, 50/60 Hz, 0.6A;

Output: 24V 1A)

• International Plug Adapters: NEMA 1-15P North America;

AS/NZS 3112 Australia; BS 1363 U.K.; CEE 7/16 Schuko

• Mounting Hardware

• Owner’s Manual

B127M-100-H Receiver Unit

• Mounting Hardware

• Owner’s Manual

B127M-101-H Extender Kit

• External Power Supply (Input: 100-240V, 50/60 Hz, 0.6A;

Output: 24V 1A)

• International Plug Adapters: NEMA 1-15P North America;

AS/NZS 3112 Australia; BS 1363 U.K.; CEE 7/16 Schuko

• Mounting Hardware

• Owner’s Manual

Optional Accessories

• N202-Series Cat6 24 AWG Solid-Wire Patch Cables

• P569-XXX-CERT or P568-XXX-2A Series High-Speed HDMI 2.0

Cables

Product Features

B127M-004-H

• Split and extend an HDMI signal to four receivers up to 230 ft.

(70 m) away over STP Cat6 cabling

• Supports video resolutions up to 4K x 2K (3840 x 2160) @

60 Hz, as speciﬁed in HDMI 2.0, with 4:4:4 Chroma

Subsampling

• Support up to 7.1-channel surround sound audio

• Power-over-Cable (PoC) technology provides power from splitter

unit to all connected receiver units

• HDCP 2.2 and HDR-compatible

• Multi-resolution support allows all connected receivers to

connect to any 1080p, 4K/30 Hz or 4K/60 Hz HDMI display

without affecting the resolution of the other connected displays

• Local HDMI port supports 4K/60 Hz video

• Meets IEC 61000-4-2 (ESD) Test Level 4 Standard (8 KV

Contact, 15 KV Air), IEC 60601-1-2 & CISPR 11 Group 1

Class EMI/RFI Standards for medical environments

• Includes mounting hardware that enables the splitter unit to be

wall-mounted, rack-mounted or pole-mounted

• Plug-and-play – no software or drivers required

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	B127M-100-H
Vekt:	450 g
Bredde:	115 mm
Dybde:	62.4 mm
Høyde:	27 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	340 g
HDCP:	Ja
3D:	Ja
Materiale:	Metall
Fargedybde:	36 bit
HDCP-versjon:	2.2
Antall HDMI-utganger:	1
Produktfarge:	Sort
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Monteringssett:	Ja
Pakkebredde:	214.1 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-5 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	CE, REACH, RoHS
Modell/Type:	AV-mottaker
RJ-45-inngangsporter:	1
Lydsystem:	Flerkanal
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Lyd-utgang kanaler:	7.1 kanaler
Strøm over Ethernet (PoE):	Ja
Bærekraftsamsvar:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332262582
Masterkassens (ytterkassens) bruttovekt:	3700 g
Masterkassens (ytterkassens) lengde:	175 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	227.1 mm
Maksimal overføring avstand:	70 m
Kabeltyper som støttes:	Cat6, HDMI
Extended display identification data (EDID):	Ja
