Side 1/20

Quick Start Guide

Active DisplayPort™/

Mini DisplayPort to DVI-D

Dual Link Adapter

Models: P134-06N-DVI-DL, P137-06N-DVI-DL

Español 6 • Français 11 •  16

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

16-08-023-93361C.indb 1 8/19/2016 4:52:08 PM

Product Features

System Requirements

Package Contents

• Actively converts all DisplayPort signals, even

non-DP ++ Single-Mode signals (e.g. AMD

Eyeﬁnity graphics cards) that won’t work with

passive adapters

• Supports video resolutions up to 2500 x

1600 with DVI Dual Link Displays or 1920 x

1080 (1080p) with DVI Single-Link Displays

• DisplayPort 1.1a compliant

• Supports 24-bit deep color

(8 bits per channel)

• Plug-and-play; no software or drivers needed

and no external power required

• Display with a DVI output port

• Computer with a DisplayPort or Mini

DisplayPort, and USB port

• P134-06N-DVI-DL or P137-06N-DVI-DL

• Quick Start Guide

16-08-023-93361C.indb 2 8/19/2016 4:52:08 PM

Optional Accessories

Installation

• P560-Series DVI Dual Link Cables

• P561-Series DVI Single-Link Cables

Note: Make sure the power to all devices you are

connecting is turned off prior to installation.

1. Connect the DVI output port on the unit to a

display using a DVI cable, such as Tripp Lite’s

P560-Series DVI Dual Link Cables.

2. Connect the built-in DisplayPort/

Mini DisplayPort cable on the unit to the

DisplayPort/Mini DisplayPort source.

3. Connect the built-in USB cable on the unit to

the source.

4. Turn on the power to all devices.

16-08-023-93361C.indb 3 8/19/2016 4:52:08 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	P134-06N-DVI-DL
Strømkilde:	USB
Maksimal oppløsning:	2560 x 1600 piksler
Opprinnelsesland:	Vietnam
Pakkevekt:	90 g
Antall per pakke:	1 stykker
Fargedybde:	24 bit
Tilkobling 1:	DisplayPort
Tilkobling 2:	DVI-D + USB
Kabellengde:	0.15 m
Produktfarge:	Sølv
Pakkedybde:	89.9 mm
Pakkehøyde:	30 mm
Pakkebredde:	154.9 mm
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080), 2560 x 1600 (WQXGA)
Støttede videofunksjoner:	1080i, 1080p
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84733080
Plugg inn og spill:	Ja
Kontaktplettering:	Gull
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332198713
Masterkassens (ytterkassens) bruttovekt:	1100 g
Masterkassens (ytterkassens) lengde:	169.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	320 mm
Masterkassens (ytterkassens) høyde:	100.1 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
Omformertype:	Passiv
