Side 1/64

Owner’s Manual

4K/60 HDMI over Cat6 Extenders

and Splitters, Multi-Resolution

Function Support

Local Unit Models: B127P-002-H, B127P-004-H

Remote Unit Models: B127P-100-H, B127P-100-H-SR

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Español 17 • Français 33 • Русский 49

Package Contents

Product Features

B127P-002-H

B127P-004-H

B127P-100-H

B127P-100-H-SR

Local (L) Unit or Remote (R) Unit L L R R

External Power Supplies (0 or 1) 1 1 0 0

Mounting Hardware Y Y Y N

All

• Support a maximum video resolution of 4K (3840 x 2160) @

60 Hz with 4:4:4 Chroma Subsampling

• Support up to 7.1-channel surround sound audio

• HDMI 2.0, HDCP 2.2 and HDR compatible

• Plug and play—no software or drivers required

Product Features

B127P-002-H

• 2-Port HDMI over Cat6 Extender/Splitter Local Transmitter Unit

• Splits an HDMI signal into two

• Works in tandem with Tripp Lite’s B127P-100-H and B127P-100-H-SR

receiver units to extend an HDMI signal

• Power over Cable (PoC) function to transfer power to remote receivers

• Supports 4K (3840 x 2160) @ 60 Hz and 1080 @ 60 Hz signals

• Multi-resolution function allows displays with varying resolutions to co-

exist in a single application without downgrading signal quality to the

lowest resolution

• Includes mounting hardware that allows unit to be wall-mounted, rack-

mounted or pole-mounted

B127P-004-H

• 4-Port HDMI over Cat6 Extender/Splitter Local Transmitter Unit

• Splits an HDMI signal into four

• Works in tandem with Tripp Lite’s B127P-100-H and B127P-100-H-SR

receiver units to extend an HDMI signal

• Power over Cable (PoC) function to transfer power to remote receivers

• Supports 4K (3840 x 2160) @ 60 Hz and 1080 @ 60 Hz signals

• Multi-resolution function allows displays with varying resolutions to co-

exist in a single application without downgrading signal quality to the

lowest resolution

• Includes an additional HDMI port, which can be used to connect a

local monitor or to daisy-chain additional B127P-004-H units (up to

three units can be daisy-chained together)

• Includes mounting hardware that allows unit to be wall-mounted, rack-

mounted or pole-mounted

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	B127P-100-H
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	340 g
Sertifisering:	CE, FCC, REACH
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
Materiale:	Metall
HDMI-versjon:	2.0
HDCP-versjon:	2.2
Antall HDMI-utganger:	1
Mottakervekt:	200 g
Produktfarge:	Sort
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Pakkebredde:	214.1 mm
Pakketype:	Boks
Støttede videofunksjoner:	2160p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-mottaker
RJ-45-inngangsporter:	1
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Lyd-utgang kanaler:	7.1 kanaler
Monteringsbeslag inkludert:	Ja
Strøm over Ethernet (PoE):	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332239201
Masterkassens (ytterkassens) bruttovekt:	3700 g
Masterkassens (ytterkassens) lengde:	227.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	175 mm
Maksimal overføring avstand:	38 m
Kabeltyper som støttes:	Cat6
Extended display identification data (EDID):	Ja
