Side 1/12

DisplayPort Over Cat6 Pigtail

Extender Kits and Receiver

with Repeater, 4K/60 Hz

Extender Kit: B127U-111-PDPD

2-Port Splitter Kit: B127U-002-PDPD2

Receiver with Repeater: B127U-110-PD

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

Este manual está disponible en español en la página de Tripp Lite: tripplite.com

Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com

Русскоязычная версия настоящего руководства представлена на

веб-сайте компании Tripp Lite по адресу: tripplite.com

Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar:

tripplite.com

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

B127U-111-PDPD

• DisplayPort over Cat6 Pigtail Transmitter and Receiver with

Repeater Kit

• Extends a 4K x 2K (3840 x 2160) @ 60 Hz DisplayPort 1.2

A/V signal up to 230 ft. (70 m) from the source over 24 AWG

Cat6 cabling

• Transmitter and receiver units can be powered by the built-

in 1 ft. USB-A cables for connecting to the USB port on a

display or to a USB power adapter, or by the Micro-USB

ports on each unit

• 1 ft. DisplayPort connectors on transmitter and receiver units

connect to the source and display

• View the transmitted video content on a local display via the

4K/60 Hz HDMI port on the transmitter unit

• Daisychainable up to 4 layers, with each additional

B127U-110-PD receiver unit (sold separately) providing an

additional 230 ft., up to a total of 920 ft. (280 m)

• Supports passthrough audio formats up to 7.1-channel

surround sound

• Real-time video compression and decompression technology

• Compatible with HDCP 2.2 and 1.4 and High Dynamic

Range (HDR)

Product Features

B127U-002-PDPD2

• 2-Port DisplayPort over Cat6 Pigtail Splitter and Receivers

Kit

• Extends a 4K x 2K (3840 x 2160) @ 60 Hz DisplayPort A/V

signal to two displays up to 230 ft. (70 m) from the source

over 24 AWG Cat6 cabling

• Transmitter and receiver units are powered by built-in 1 ft.

USB-A cables for connecting to the USB port on a display or

to a USB power adapter, or via the Micro USB ports on each

unit

• Multi-Resolution technology allows the receivers to connect

to any 1080p, 4K/30 Hz or 4K/60 Hz display without a󰀨ecting

the resolution of the other displays connected to the splitter

• 1 ft. DisplayPort connectors on transmitter and receiver units

connect to the source and display

• Supports passthrough audio formats up to 7.1-channel

surround sound

• Real-time video compression and decompression technology

• Compatible with HDCP 2.2 and 1.4 and High Dynamic

Range (HDR)

• Compatible with DisplayPort (B127U-110-PD) and HDMI

(B127U-110-PH) receivers to create exible daisychain

installations with multiple video outputs. Each port on the

splitter can extend up to four connected receivers, for a total

of eight receivers and 920 ft. (280 m) per daisychain (sold

separately).

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	AV ekstender
Modell:	B127U-002-PDPD2
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Oppløsning:	3840 x 2160 piksler
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Pakkevekt:	640 g
HDCP:	Ja
3D:	Ja
Materiale:	Plast
Antall per pakke:	1 stykker
Fargedybde:	36 bit
DisplayPorts inn:	1
DisplayPorts ut:	1
HDCP-versjon:	1.4/2.2
Mottakervekt:	250 g
Kabellengde:	0.3 m
Støttede lydformater:	LPCM
Produktfarge:	Black, Grey
Antall USB-porter:	3
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Pakkebredde:	260.1 mm
Støttede grafikkoppløsninger:	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160
Pakketype:	Boks
Støttede videofunksjoner:	720p, 1080p, 2160p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	CE, Federal Communications Commission (FCC), REACH, RoHS, Trade Agreements Act (TAA), UKCA, WEEE
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	2
USB-strøm:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Nei
HDR (High Dynamic Range) støttes:	Ja
Bærekraftsamsvar:	Ja
Maksimal overføring avstand:	70 m
Trådløs mottaker (B x D x H):	47 x 75 x 18.6 mm
Senderdimensjoner (BxDxH):	47 x 75 x 18.6 mm
Sendervekt:	250 g
RJ-45-utgangsporter:	4
Seriekobling:	Ja
Extended display identification data (EDID):	Ja
