Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

DVI over Cat5 Extenders

and Extender/Splitters

Extender Kit Models:

B140-101, B140-1P1-WP-1, B140-101X, B140-1A1-WP

Local Unit Models: B140-002 and B140-004

Remote Unit Models: B140-1P0, B140-1A0,

B140-1A0-WP-1 and B140-110

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

Este manual esta disponible en español en la página de Tripp Lite:

www.tripplite.com/support

Ce manuel est disponible en français sur le site Web de Tripp Lite :

www.tripplite.com/support

Русскоязычная версия настоящего руководства

представлена на веб-сайте компании Tripp Lite по адресу:

www.tripplite.com/support

17-08-507-933094-EN.indd 1 9/25/2017 12:51:30 PM

Table of Contents

Package Contents ................................................................................3

Product Features .................................................................................3

Mounting (Optional) ............................................................................8

Standard Extender Kit Installation .......................................................... 9

Extender Kit with Remote/Repeater Installation ....................................11

(B140-101X and B140-1A1-WP extender kits only)

Standard Extender/Splitter Installation ..................................................14

Extender/Splitter with Remote/Repeater Installation .............................. 17

(B140-1A0 and B140-1A0-WP-1 remote receiver units only)

Extender/Splitter Daisy-Chain Installation .............................................. 20

Extender/Splitter Daisy-Chain with Remote/Repeater Installation ............ 22

(B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP

remote receivers only)

Warranty and Product Registration ....................................................... 27

17-08-507-933094-EN.indd 2 9/25/2017 12:51:30 PM

Package Contents

Product Features

B140-101

B140-1P1-WP-1

B140-101X

B140-1A1-WP

B140-002

B140-004

B140-1A0

B140-1A0-WP-1

B140-1P0

B140-110

Local Unit (L), Remote Unit (R), or

Both (B)

B B B B L L R R R R

External Power Supplies (0, 1, or 2) 0 0 1 2 1 1 1 1 0 1

Mounting Hardware X X X X X

Wallplate Screws X X X

Screwdriver for Equalization

Adjustment

X X X X X

DVI Daisy-chain Cable X

All

• Support DVI-D Single-Link video resolutions up to 1920 x 1080 (60 Hz)

• Plug-and-play; no software or drivers required

• Compatible with all major operating systems

• HDCP compatible

B140-101

• DVI over Cat5 Passive Extender Kit (Box-style)

• Extend a 1024 x 768 (60 Hz) signal up to 100 ft. (30.5 m) from the

source, or a 1920 x 1080 (60 Hz) signal up to 50 ft. (15 m) from the

source

• No external power required

17-08-507-933094-EN.indd 3 9/25/2017 12:51:30 PM
