Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

DVI over Cat5 Extenders

and Extender/Splitters

Extender Kit Models:

B140-101, B140-1P1-WP-1, B140-101X, B140-1A1-WP

Local Unit Models: B140-002 and B140-004

Remote Unit Models: B140-1P0, B140-1P0-WP-1,

B140-1A0, B140-1A0-WP-1 and B140-110

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Package Contents 2

Product Features 2

Mounting (Optional) 8

Standard Extender Kit Installation 9

Extender Kit with Remote/Repeater Installation 11

(B140-101X and B140-1A1-WP extender kits only)

Standard Extender/Splitter Installation 14

Extender/Splitter with Remote/Repeater Installation 17

(B140-1A0 and B140-1A0-WP-1 remote receiver units only)

Extender/Splitter Daisy-Chain Installation 20

Extender/Splitter Daisy-Chain with Remote/Repeater Installation 22

(B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP

remote receivers only)

Warranty & Warranty Registration 27

201110026-93-3094-EN.indd 1 11/3/2011 11:37:06 AM

Package Contents

Product Features

B140-101

B140-1P1-WP-1

B140-101X

B140-1A1-WP

B140-002

B140-004

B140-1A0

B140-1A0-WP-1

B140-1P0

B140-1P0-WP-1

B140-110

Local Unit (L), Remote Unit

(R), or Both (B)

B B B B L L R R R R R

External Power Supplies

(0, 1, or 2)

0 0 1 2 1 1 1 1 0 0 1

Mounting Hardware X X X X X

Wallplate Screws X X X X

Screwdriver for Equalization

Adjustment

X X X X X

DVI Daisy-chain Cable X

All

• SupportDVI-DSingle-Linkvideoresolutionsupto1920x1080(60Hz)

• Plug-and-play;nosoftwareordriversrequired

• Compatiblewithallmajoroperatingsystems

•HDCPcompatible

B140-101

• DVIoverCat5PassiveExtenderKit(Box-style)

• Extenda1024x768(60Hz)signalupto100ft.fromthesource,or

a1920x1080(60Hz)signalupto50ft.fromthesource

• Noexternalpowerrequired

201110026-93-3094-EN.indd 2 11/3/2011 11:37:06 AM

Product Features

B140-1P1-WP-1

• DVIoverCat5PassiveExtenderWallplateKit

• Extenda1024x768(60Hz)signalupto75ft.fromthesource,ora

1920x1080(60Hz)signalupto50ft.fromthesource

• RJ45-stylewallplatesallowfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

• Noexternalpowerrequired

B140-101X

• DVIoverCat5ActiveExtenderKit(Box-style)

• Extenda1024x768(60Hz)signalupto200ft.fromthesource,or

a1920x1080(60Hz)signalupto150ft.fromthesource

• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo

image adjustment

• Includesmountinghardwarethatallowsremoteunittobe

wallmounted, rackmounted or pole mounted
