Owner’s Manual

Audio/Video with RS-232

and IR Control over IP Extenders

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Extender Kit Models:

B160-101-DPSI

B160-101-DPHDSI

B160-101-HDSI

B160-103-HDSI

B160-201-HSI

B160-202-HDSI

B160-301-HDSI

Transmitter Models:

B160-001-CSI

B160-001-DPSI

B160-001-HDSI

B160-001-VSI

Receiver Models:

B160-100-CSI

B160-100-DPSI

B160-100-HDSI

B160-100-VSI

B160-200-HSI

WARRANTY REGISTRATION

an ISOBAR surge protector in our monthly drawing!

www.tripplite.com/warranty

Español 25 • Français 50 • Русский 75

Package Contents

B160-001-CSI

B160-001-DPSI

B160-001-HDSI

B160-001-VSI

B160-100-CSI

B160-100-DPSI

B160-100-HDSI

B160-100-VSI

B160-200-HSI

B160-101-DPSI

B160-101-DPHDSI

B160-101-HDSI

B160-103-HDSI

B160-201-HSI

B160-202-HDSI

B160-301-HDSI

Transmitter (T),

Receiver (R), Kit (K)

T T T T R R R R R K K K K K K K

External Power Supply 1 1 1 1 1 1 1 1 1 2 2 2 4 2 4 4

IR-In Cable 0 0 0 0 1 1 1 1 1 1 1 1 1 1 2 3

IR-Out Cable 1 1 1 1 0 0 0 0 0 1 1 1 3 1 2 1

3.5 mm to DB9 M/F

Adapter Cable

1 1 0 1 0 0 0 0 0 1 1 0 3 0 2 1

3.5 mm to DB9 M/M

Adapter Cable

0 0 0 0 1 1 0 1 1 1 1 0 1 1 2 3

HDMI to DVI

Adapter Cable

0 0 1 0 0 0 1 0 0 0 1 2 4 0 4 4

Mounting Hardware Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

Owner’s Manual Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

Optional Accessories

• A008-006 Component Video Gold Cable – 6 ft.

• N202-Series Cat6, 24 AWG, Solid-Wire Patch Cables

• NSS-G16D2 16-Port Gigabit L2 Managed Switch with 8-Outlet PDU

• NSS-G24D2 24-Port Gigabit L2 Managed Switch with 12-Outlet PDU

• P502-Series VGA Cables with RGB Coax

• P520-006 RS-232 Serial Extension Cable – 6 ft.

• P561-Series DVI-D Single-Link Cables

• P566-Series HDMI to DVI Adapter Cables

• P568-Series High-Speed HDMI Cables

• P569-XXX-LOCK* High-Speed HDMI Cables with Ethernet and Locking

Connectors

• P580-Series DisplayPort™ Cables

• P583-Series Mini DisplayPort to DisplayPort Cables

*XXX refers to the length, with cables available in 6 ft. (006), 10 ft. (010) and

15 ft. (015) lengths.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	B160-301-HDSI
Bredde:	100 mm
Dybde:	128 mm
Høyde:	29.7 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	1920 x 1080 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	3540 g
Sertifisering:	CE, FCC, REACH
Maksimal oppdateringshastighet:	60 Hz
3D:	Ja
Materiale:	Metall
Fargedybde:	24 bit
Utgangsstrøm:	2 A
HDMI inn:	2
Antall HDMI-utganger:	1
Driftsspenning:	5 V
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Mottakervekt:	1499.3 g
Kabellengde:	1.4 m
Produktfarge:	Sort
Pakkedybde:	337.8 mm
Pakkehøyde:	121.9 mm
Monteringssett:	Ja
Pakkebredde:	271.8 mm
Kabler inkludert:	AC, IR
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
Ekstern strømadapter:	Ja
Inkluderte kraftpluggtyper:	AU, EU, NA, UK
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
AC-adapter bunt:	Ja
Innput-strøm:	0.5 A
Maksimal overføring avstand:	200 m
Kabeltyper som støttes:	Cat5, Cat6
Trådløs mottaker (B x D x H):	100 x 128 x 29.7 mm
Senderdimensjoner (BxDxH):	100 x 128 x 29.7 mm
Sendervekt:	1499.3 g
RJ-45-utgangsporter:	1
3,5 mm inn:	Ja
3.5 mm ut:	Ja
