Owner’s Manual

Extended-Run Battery Cabinet

Models: BP240V09, BP240V09K, BP240V09-NIB, BP240V40,

BP240V40-NIB, BP240V40L, BP240V40L-NIB

Not suitable for mobile applications.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Español 76 • Français 151

Table of Contents

1. Introduction 3

1.1 Features 3

1.2 UPS and Battery Cabinet 4

Compatibility

2. Important Safety Instructions 5

2.1 Installation and Location Warnings 5

2.2 Connection Warnings 5

2.3 Battery Warnings 6

3. Battery Cabinet Installation 7

3.1 Preparation 7

3.2 Transportation 7

3.3 Mechanical Check 7

3.4 Package Contents 8

3.5 Internal Wiring (Typical) 8

3.6 Battery Cabinet Placement 9

3.7 Electrical Connection 9

3.8 Final Electrical Check 10

4. Mechanical Data 11

4.1 Physical Measurements 11

4.1.1 BP240V09, BP240V09K and 11

BP240V09-NIB

4.1.2 BP240V40 and BP240V40-NIB 13

4.1.3 BP240V40L and BP240V40L-NIB 15

4.2 Physical Requirements 17

5. Installation 18

5.1 Unpacking and Inspection 18

5.2 Selecting Installation Position 21

5.3 Power Cables 22

5.3.1 Cable Sizes 22

5.4 Internal Battery Installation – 22

Model BP240V09-NIB

5.4.1 Battery Installation and Setup 23

5.4.2 Battery Connection 37

5.4.3 Voltage Check 39

5.5 Internal Battery Installation – 39

Model BP240V40-NIB

5.5.1 Battery Installation and Setup 40

5.6 Internal Battery Installation – 47

Model BP240V40L-NIB

5.6.1 Battery Installation and Setup 48

5.6.2 Battery Installation and Connection 55

5.6.3 Voltage Check 56

5.7 Multiple Battery Pack Connections 57

5.7.1 Models BP240V09, BP240V09K 57

BP240V09-NIB

5.7.2 Models BP240V40, BP240V40-NIB 58

5.7.3 Models BP240V40L, 59

BP240V40L-NIB

6. Operation and Conﬁguration of 61

S3M UPS Models and

Battery Cabinets

6.1 S3M10-50K UPS Compatibility 61

with BP240V09 to BP240V40L

Battery Cabinet Models

6.2 Conﬁguring 10-20K UPS for 61

Speciﬁc Battery Cabinets using

the LCD Display

6.2.1 S3M10-20K UPS Home Display 62

6.2.2 Setting 62

6.2.3 Battery Setup 63

6.2.4 Conﬁguring the S3M10-20K UPS 63

and Optimizing Charging of the

BP240V09/BP240V09K, BP240V40

and BP240V40L Battery Cabinets

6.3 Conﬁguring 25-100K UPS for 66

Speciﬁc Battery Cabinets Using

the LCD Display

6.3.1 S3M25-100K UPS Home Display 66

6.3.2 Setting 67

6.3.3 Battery Setup 68

6.3.4 Conﬁguring the S3M25-50K 69

UPS and Optimizing Charging of the

BP240V09/BP240V09K, BP240V40

or BP240V40L Battery Cabinets

6.4 Conﬁguration Reference Table for 71

S3M10-50K UPS and

BP240V09/09K/09-NIB and

BP240V40/40-NIB/40L/40L-NIB

Battery Cabinet Models

7. Speciﬁcations 73

8. Storage and Service 74

9. Warranty 75

1. Introduction

Tripp Lite’s Extended-Run Battery Cabinets connect to SmartOnline® UPS Systems to provide long-lasting battery backup

for data centers, telecommunications, networks, industrial facilities, security, emergency systems and other mission-critical

applications that require high capacity, high availability and extended runtime.

Battery cabinets are available in seven options, with pre-installed batteries and without: BP240V09, BP240V09K,

BP240V09-NIB, BP240V40, BP240V40-NIB, BP240V40L and BP240V40L-NIB.

The “-NIB” sufﬁx battery cabinet models BP240V09-NIB, BP240V40-NIB and BP240V40L-NIB do not include pre-installed

batteries. However, they include all of the jumper cables, fuses and breakers, enabling the ﬂexibility to purchase batteries

separately for the battery cabinet. The BP240V09-NIB battery cabinet is designed for CSB HR1234W F2 or similar 9Ah

batteries. The BP240V40-NIB and BP240V40L-NIB battery cabinets are designed for CSB GP12400i batteries.

1.1 Features

• The battery cabinets are designed for battery string voltages of ± 120V DC and battery capacities of 9Ah or 40Ah, @ C20

to 1.67VPC.

• Battery cabinets contain multiple 12V DC AGM batteries connected in series to achieve higher voltages.

• Each battery cabinet contains several shelves to achieve the required battery string voltages:

o BP240V09 / BP240V09K / BP240V09-NIB: holds 80 x 9Ah AGM batteries

o BP240V40 / BP240V40-NIB: holds 20 x 40Ah AGM batteries

o BP240V40L / BP240V40L-NIB: holds 40 x 40Ah AGM batteries

• Hinged lockable door facilitates access to batteries for periodic maintenance.

• A minimum of 4 in. (100 mm) clearance is located above the individual batteries for access to terminals.

• The battery cabinet is constructed of heavy-gauge steel for durability.

• A baked powder-coat ﬁnish provides corrosion resistance.

• The battery cabinet ships bolted to a pallet with a double layer of protective stretch wrap and integrated corner and top

protection.

• Appropriate ventilation and convection cooling of individual batteries is provided via spacing between batteries. Front and

rear vents allow the free ﬂow of warmer air out of the battery cabinet.

• A molded case circuit breaker is provided for overcurrent protection.

• User-supplied power output cables can be fed into the battery cabinet via built-in conduit knockouts on the bottom of the

cabinet for BP240V40/40L/40-NIB/40L-NIB models, and with an included cable for BP240V09/09K/09-NIB models at the

rear of the cabinet.

• For improved safety, higher power density and minimized maintenance, the cabinet systems use Valve-Regulated Lead-Acid

(VRLA) recombinant batteries. The electrolyte in these batteries is immobilized in either an absorbent mat separator or a

gelling medium, eliminating the spilling hazards and maintenance requirements of free liquid electrolyte. There is no need to

add water or measure speciﬁc gravity.

• Because the batteries are recombinant cells that employ an oxygen recombination cycle, minimal gasses are emitted during

normal ﬂoat charging. Each cell contains an individual valve, which releases the gas products from overcharge and prevents

pressure build-up within the cell.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteri
Modell:	BP240V09
Vekt:	279230 g
Bredde:	248.9 mm
Dybde:	899.2 mm
Høyde:	868.7 mm
Bruksanvisning:	Ja
Batterikapasitet:	9 Ah
Opprinnelsesland:	China
Pakkevekt:	285260 g
Antall hjul:	4 hjul
Kompatible produkter:	S3M10K1B, S3M10K2B, S3M10K3B, S3M10K-NIB, S3M15K2B, S3M15K3B, S3M15K-NIB, S3M20K3B, S3M20K-NIB
Batteriteknologi:	Forseglet blysyre (VRLA)
Produktfarge:	Sort
Pakkedybde:	1023.6 mm
Pakkehøyde:	1049 mm
Pakkebredde:	375.9 mm
Antall støttede batterier:	80
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Kroppsmateriale:	Stål
Svinghjul:	Ja
Masterkassens (ytterkassens) bruttovekt:	285260 g
Masterkassens (ytterkassens) lengde:	1023.6 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	375.9 mm
Masterkassens (ytterkassens) høyde:	1049 mm
Antall:	1
