1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Owner’s Manual

Extended-Run

Battery Cabinet

Models: BP480V40, BP480V40-NIB, BP480V65,

BP480V65-NIB, BP480V100, BP480V100-NIB

Not suitable for mobile applications.

Español 36 • Français 71 • Русский 106 • Deutsch 141

18-09-176-933861.indb 1 9/26/2018 10:54:10 AM

Table of Contents

1. Introduction 3

Features 3

2. Important Safety 4

Instructions

Installation and 4

Location Warnings

Connection Warnings 4

Battery Warnings 5

3. Battery Cabinet Installation 7

3.1 Preparation 7

3.2 Transportation 7

3.3 Mechanical Check 7

3.4 Internal Wiring (Typical) 8

3.5 Preliminary Electrical Check 8

(After Battery Installation)

3.6 Battery Cabinet Placement 8

3.7 Electrical Connection 9

3.8 Final Electrical Check 10

4. Operation and Charging 11

4.1 Determine Charging Voltages 11

4.2 Initial Charge 11

4.3 Operational Check 11

5. Maintenance 11

5.1 Maintenance Schedule 11

5.1.1 Quarterly Check 11

6. Mechanical Data 12

6.1 Physical Measurements 12

6.1.1 BP480V40/NIB 12

Measurements

6.1.2 BP480V65/NIB and 13

BP480V100/NIB

Measurements

6.2 Battery Requirements 14

6.2.1 BP480V40/NIB Battery 14

6.2.2 BP480V65/NIB Battery 14

6.1.3 BP480V100/NIB Battery 14

7. Installation 15

7.1 Battery Pre-Installation 15

7.2 Cable Jumpers and 16

Internal Wiring

7.2.1 Included Cable 16

Jumpers Speciﬁcations

7.2.2 Installing Cable Jumpers 17

to Battery Terminals

7.2.3 Battery Cabinet 18

Internal Wiring

7.3 Battery Installation 21

7.4 Installation Speciﬁcations 33

7.4.1 Installation and 33

Floor Loading Information

7.4.2 Recommended Torque 33

8. Storage and Service 34

9. Warranty 35

18-09-176-933861.indb 2 9/26/2018 10:54:10 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteri
Modell:	BP480V40
Vekt:	103300 g
Bredde:	626.1 mm
Dybde:	899.9 mm
Høyde:	1220 mm
Batterikapasitet:	40 Ah
Opprinnelsesland:	China
Pakkevekt:	146800 g
Antall batterier inkludert:	40 stykker
Kompatibilitet:	S3M30KX-NIB, S3M40KX-NIB, S3M60KX, S3M80KX, S3M100KX, S3M120KX, S3M160KX, S3M200KX
Batteriteknologi:	Forseglet blysyre (VRLA)
Produktfarge:	Sort
Pakkedybde:	203.2 mm
Pakkehøyde:	1396 mm
Pakkebredde:	184.2 mm
Bærekraftsertifikater:	RoHS
Masterkassens (ytterkassens) bruttovekt:	146800 g
Masterkassens (ytterkassens) lengde:	1125 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	705.1 mm
Masterkassens (ytterkassens) høyde:	1396 mm
