Owner’s Manual

Extended-Run Battery Cabinet

Not suitable for mobile applications.

BP192V787C-1PH (Single-Phase),

BP480V200 and All BP240V Models

BP480V300 and BP480V400 Models BP480V500 Model

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

1. Table of Contents

1. Introduction 3

2. Important Safety Instructions 4

3. Battery Cabinet Installation 6

3.1 Preparation 6

3.2 Transportation 6

3.3 Mechanical Check 6

3.4 Internal Wiring (Typical) 7

3.5 Preliminary Electrical Check 7

3.6 Battery Cabinet Placement 7

3.7 Electrical Connection 8

3.8 Battery Charger Electrical Connection 8

(Select Models)

3.9 Final Electrical Check 8

4. Operation and Charging 9

4.1 Determine Charging Voltages 9

4.2 Initial Charge 9

4.3 Operational Check 9

4.4 Acceptance Test (Optional) 9

5. Maintenance 10

5.1 Maintenance Schedule 10

6. Diagrams 11

6.1 Battery Cabinet Diagrams 11

6.1.1 BP192V787C-1PH Model (2 Shelves) 11

6.1.2 All BP240V Models (3 Shelves) 12

6.1.3 BP480V200 Model (4 Shelves) 13

6.1.4 BP480V300 and BP480V400 Models 14

(4 Shelves)

6.1.5 BP480V500 Model (4 Shelves) 15

6.2 Battery and Breaker Diagrams 16

6.2.1 192 VDC (Single-Phase) 16

6.2.2 240 VDC (Single-Phase) 17

6.2.3 240 VDC (3-Phase) 18

6.2.4 +/- 240 VDC (3-Phase) 19

6.2.5 EBP-Series (+/- 120 VDC) 20

6.2.6 Busbar Connections for 21

Multi-Cabinet Systems

6.3 Integrated 7A Battery Charger 23

(Select Models)

7. Speciﬁcations 24

7.1 Dimensions and Floor Loading 24

7.2 Recommended Torque 25

8. Storage and Service 26

9. Warranty 26

Español 27

Русский 53

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteri
Modell:	BP480V500
Vekt:	2062940 g
Bredde:	1016 mm
Dybde:	749.3 mm
Høyde:	1999 mm
Opprinnelsesland:	Taiwan
Pakkevekt:	2062940 g
Sertifisering:	TAA
Kompatibilitet:	SU40K, SU60K, SU80K, SU20KX, SU40KX, SU60KX, SU80KX, SU60KTV, SU80KTV
Produktfarge:	Sort
Pakkedybde:	1117.6 mm
Pakkehøyde:	2159 mm
Pakkebredde:	1295.4 mm
Batterispenning:	240 V
Bærekraftsertifikater:	RoHS
Masterkassens (ytterkassens) bruttovekt:	2062940 g
Masterkassens (ytterkassens) lengde:	1117.6 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	1295.4 mm
Masterkassens (ytterkassens) høyde:	2159 mm
