Owner’s Manual

Heavy-Duty Rolling TV/Monitor Cart

with Crank Handle

Model: DMCS60100XXCK

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR!

200 x 200 / 300 x 300

400 x 200 / 400 x 400

600 x 400 / 800 x 400

800 x 600 / 1000 x 600

100"

MAX

TVTV

220 lb./100 kg220 lb./100 kg

MAXMAX

DVDDVD

11 lb./5 kg (x2)11 lb./5 kg (x2)

MAXMAX

CAMERACAMERA

11 lb./5 kg11 lb./5 kg

MAXMAX

Español 12 • Français 23 • Русский 34 • Deutsch 45

Safety Instructions

Warranty and Product Registration

WARNING

• Do not begin the installation until you have read and understood the instructions and warnings contained in this

manual. If you have any questions regarding any of the instructions or warnings, please visit tripplite.com/support.

• This mounting bracket was designed to be installed and utilized ONLY as speciﬁed in this manual. Improper installation

of this product may cause damage or serious injury.

• This product should only be installed by someone of good mechanical ability, with basic building experience and a full

understanding of this instruction manual.

• Make sure that the mounting surface can safely support the combined load of the equipment and all attached hardware

and components.

• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. The use of

a stud ﬁnder is highly recommended.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws ﬁrmly, but do not over-tighten. Over-tightening screws can damage the items, greatly reducing their

holding power.

•

This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of

5 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the

product, in its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO

EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED

WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE;

AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied

warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may

not apply to you. This warranty gives you speciﬁc legal rights, and you may have other rights, which vary from jurisdiction to jurisdiction).

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since

individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or ﬁtness of these devices

for any speciﬁc application.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE

Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice. Photos and illustrations may differ slightly from

actual products.

NOTE: Read the entire Owner’s Manual before you start installation and assembly.

Package M

Package P

Component Checklist

IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing.

If any parts are missing or faulty, visit tripplite.com/support for service.

Left Leg (x1)

Left Cover (x1)

Right Leg (x1)

Universal Plate (x1)

Right Column (x1)

Top Cover (x1)

Connecting Plate (x1)

Right Cover (x1)

Left Column (x1)

Left Adapter Bracket (x1)

Upper DVD Shelf (x1)

Connecting Bar (x1)

Right Adapter Bracket (x1)

Lower DVD Shelf (x1)

Plastic Cover (x2)

Crank Handle (x1)

Camera Shelf (x1)

Plastic Handle (x2)

Caster (x4)

Middle Base (x1)

M-A

M5x14 (x4)

M-E

M8x50 (x4)

M-B

M6x14 (x4)

M-F

D5-D8 (x4)

M-C

M6x30 (x4)

M-D

M8x30 (x4)

M-G

Ø15xØ8x5 (x8)

M-H

Ø15xØ8x15 (x8)

M8x25 (x12)

M5x40 (x1)

M6x8 (x12)

M6x25 (x4)

5 mm Hex Key(x1)

M4x6 (x3)

19 mm Wrench (x1)

M4x6 (x3)

M6x14 (x4)
