Owner’s Manual

Super Heavy-Duty

Mobile Display Cart

with UL Certication &

Antimicrobial Protection

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS

INJURY OR PROPERTY DAMAGE MAY OCCUR!

200 x 200 / 300 x 200 /

300 x 300 / 400 x 200 /

400 x 300 / 400 x 400 /

600 x 400 / 800 x 400 /

800 X 600 / 1000 X 600

120"

MAX

264 lb. / 120 kg264 lb. / 120 kg

Flat-Panel Flat-Panel

TV MountTV Mount

11 lb. / 5 kg11 lb. / 5 kg

AV ShelfAV Shelf

11 lb. / 5 kg11 lb. / 5 kg

Video TrayVideo Tray

Model: DMCS70120AMUL

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 13 • Français 25 • Русский 37 • Deutsch 49

Safety Instructions

Warranty and Product Registration

WARNING

Do not begin installation until you read and understand the instructions and warnings contained in this

manual. If you have any questions regarding any of the instructions or warnings, visit tripplite.com/support.

Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote

control or toys placed on the cart may encourage a child to climb on the cart, causing it to tip over onto the child.

Relocating audio and/or video equipment to furniture not specically designed to support the audio and/or video

equipment may result in death or serious injury caused by the furniture collapsing or turning over onto a child.

Use with equipment heavier than the rated weights indicated may result in instability, causing possible injury.

• Closely follow assembly instructions. Improper installation may result in instability, causing possible injury.

• Safety gear and proper tools must be used. This product should be installed only by qualied professionals.

• Ensure the supporting surface will safely support the combined weight of the equipment and all attached hardware

and components.

• Use the mounting screws provided. DO NOT OVERTIGHTEN mounting screws.

• This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.

• This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal

injury.

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a

period of 5 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or

replace the product, in its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT.

SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT

PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE

LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND

CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion

or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal

rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since

individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or tness of these devic-

es for any specic application.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE

Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Specications are subject to change without notice. Photos and illustrations may di󰀨er slightly from

actual products.

Component Checklist

IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing.

If any parts are missing or faulty, visit tripplite.com/support for service.

Right Leg (x1)

Casters (x4)

Lower Column (x2)

Cross Bracket (x1)

Upper Column (x2)

Left TV Bracket (x1)

Right TV Bracket (x1)

Top Cover (x2)

AV Equipment Shelf (x1)

Connecting Bracket (x1)

Cable Cover (x16)

Mounting Plate Assembly (x1)

Camera Shelf (x1)

Handle (x2)

End Cap (x2)

Left Leg (x1)

Package M

M-A

M5x14 (x4)

M-E

M8x50 (x4)

M-F

Washer (x4)

M-G

Small

Spacer (x8)

M-D

M8x30 (x4)

M-C

M6x30 (x4)

M-B

M6x14 (x4)

M-H

Big Spacer

(x8)

Package P

P-A

Washer (x8)

P-B

M8x80 (x8)

P-C

M8x20

(x12)

P-E

M8x12

(x2)

P-F

Spacer

(x1)

P-D

M5x8

(x2)

P-G

M6 Wrench

(x1)

P-H

M12 Wrench

(x1)

P-I

5mm Allen Key

(x1)

P-J

6mm Allen Key

(x1)
