Owner’s Manual

Landscape/Portrait Wall

Mount for Curved- and

Flat-Panel Displays

Model: DWM3780ROT

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY.

SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR!

200x200/300x200/300x300

350x350/400x200/400x300

400x400/400x600/600x400

80"

MAX

110 lb.110 lb.

(50 kg)(50 kg)

RatedRated

Español 7 • Français 13 • Русский 19 • Deutsch 25

Important Safety Instructions

Warranty and Product Registration

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workman-

ship for a period of 5 years from the date of initial purchase. If the product should prove defective in material or workmanship within that

period, Seller will repair or replace the product, at its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER

MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY

APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION

TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAM-

AGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation

of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal

rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intend-

ed. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or

fitness of these devices for any specific application.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a

FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Images may differ slightly from actual products.

CAUTION

• Read the entire instruction manual before you start assembly and installation. If you have questions about any of the

instructions or warnings, contact Tripp Lite Support.

• Use with products heavier than the rated weights indicated may result in instability, causing possible injury.

• Mounts must be attached as specified in these instructions. Improper installation may result in damage or serious

personal injury.

• Safety gear and proper tools must be used. This product should only be installed by professionals.

• Ensure the supporting surface will safely support the combined weight of the equipment and all attached hardware

and components.

• Use the mounting screws provided and DO NOT OVERTIGHTEN the mounting screws.

• This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.

• This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

• Check that the bracket is secure and safe to use at regular intervals (at least every three months).

Component Checklist

IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing.

If any parts are missing or faulty, visit tripplite.com/support for service.

Package M Package W

A (x1)

B (x2)

C (x4) D (x4) E (x1) M-F (x4) M-G (x8) M-H (x8)

M-E (x4)

M8x50

M-D (x4)

M8x30

M-A (x4)

M5x14

M-B (x4)

M6x14

M-C (x4)

M6x30

W-A (x3)

ST8x60

W-B (x3)

ø12x60

W-C (x3)

W-D (x2)

ST6.3x50
