Owner’s Manual

Full-Motion Wall Mount for

Flat or Curved Screens –

Security Version

Model: DWMSC3780MUL

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR

PROPERTY DAMAGE MAY OCCUR!

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

300 x 300 / 400 x 200 /

400 x 400 / 600 x 400 /

800 x 400

80”

MAX

88 lb.

(40 kg)

MAX

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

Español 11 • Français 21 • Русский 31 • Deutsch 41

18-05-216-933842.indb 1 7/9/2018 12:01:36 PM

NOTE: Read the entire instruction manual before you start assembly and installation.

WARNING

• Do not begin the installation until you have read and understood the instructions

and warnings contained in this manual. If you have any questions regarding any

of the instructions or warnings, please visit www.tripplite.com/support

• This mounting bracket was designed to be installed and utilized ONLY as

speciﬁed in this manual. Improper installation of this product may cause damage

or serious injury.

• This product should only be installed by someone of good mechanical ability,

with basic building experience and a full understanding of this instruction

manual.

• Make sure that the mounting surface can safely support the combined load of

the equipment and all attached hardware and components.

• If mounting to wood wall studs, make sure that mounting screws are anchored

into the center of the studs. The use of a stud ﬁnder is highly recommended.

• Always use an assistant or mechanical lifting equipment to safely lift and position

equipment.

• Tighten screws ﬁrmly, but do not over-tighten. Over-tightening screws can

damage the items, greatly reducing their holding power.

• This product is intended for indoor use only. Using this product outdoors could

lead to product failure and personal injury.

18-05-216-933842.indb 2 7/9/2018 12:01:36 PM

Component Checklist

IMPORTANT: Ensure that you have received all parts according to the component checklist prior to

installing. If any parts are missing or faulty, visit www.tripplite.com/support for service.

Wall Plate (x1)

M5 x 14 Screw (x4)

M-A

Anchor Bolt (x5)

W-A

M8 x 20 Screw (x4)

M-E

End Cap (x2)

End Cap Screws (x4)

Combination Lock (x1)

Wall Plate Level (x1)

Security Bar (x1)

M6 x 14 Screw (x4)

M-B

Concrete Anchor (x5)

W-B

Washer (x4)

M-F

20 mm Washer (x5)

W-C

Small Spacer (x8)

M-G

M6 x 30 Screw (x4)

M-D

Big Spacer (x4)

M-H

M8 x 30 Screw (x4)

M-E

Left Adapter Bracket (x1)

Right Adapter Bracket (x1)

Anti-Skid Block (x2)

Package M

Package W

18-05-216-933842.indb 3 7/9/2018 12:01:36 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	DWMSC3780MUL
Vekt:	9980 g
Bredde:	985.5 mm
Dybde:	439.4 mm
Høyde:	548.6 mm
Opprinnelsesland:	China
Pakkevekt:	10700 g
Antall skjermer som støttes:	1
Maksimal skjermstørrelse:	37 "
Minimum skjermstørrelse:	80 "
Produktfarge:	Sort
Vippevinkelområde:	-10 - 5 °
Pakkedybde:	68.6 mm
Pakkehøyde:	1000.8 mm
Pakkebredde:	335.3 mm
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85299097
Kroppsmateriale:	Stål
Svingvinkel:	90 °
Panelmonterbart grensesnitt:	300 x 300,400 x 200,400 x 400,600 x 400,800 x 400 mm
Montasjetype:	Vegg
Maksimalvekt (kapasitet):	91 kg
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332225068
Masterkassens (ytterkassens) bruttovekt:	22320 g
Masterkassens (ytterkassens) lengde:	154.9 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	353.1 mm
Masterkassens (ytterkassens) høyde:	1018.5 mm
Monteringsgrensesnitt, kompatibilitet (min):	300 x 300 mm
Monteringsgrensesnitt, kompatibilitet (maks):	800 x 400 mm
