Owner’s Manual

Landscape Video Wall

with Security

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR!

200x200/300x300

400x200/400x400

600x400

70"

MAX

154 lb.154 lb.

(70 kg)(70 kg)

RATEDRATED

Model: DWMSCL4570VW

Important Safety Instructions

Warranty and Product Registration

CAUTION

• Read the entire instruction manual before you start assembly and installation. Do not begin installation until you have

read and understood all the instructions and warnings contained in this installation sheet. If you have questions about

any of the instructions or warnings, contact Tripp Lite Support.

• Use with products heavier than the rated weights indicated may result in instability, causing possible injury.

• Mounts must be attached as speciﬁed in these instructions. Improper installation may result in damage or serious

personal injury.

• Safety gear and proper tools must be used. This product should only be installed by professionals.

• Ensure the supporting surface will safely support the combined weight of the equipment and all attached hardware and

components.

• Use the mounting screws provided, tighten them ﬁrmly, but DO NOT OVERTIGHTEN the mounting screws. Overtightening

can cause damage to the items. This greatly reduced their holding power.

• This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.

• This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

• Check that the bracket is secure and safe to use at regular intervals (at least every three months).

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of

5 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the

product, at its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO

EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED

WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE;

AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied

warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not

apply to you. This warranty gives you speciﬁc legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since

individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or ﬁtness of these devices for

any speciﬁc application.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite

product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice. Images may differ slightly from actual products.

Package P

Package M

Package W

Component Checklist

IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing.

If any parts are missing or faulty, visit tripplite.com/support for service.

Pop-Out Module(x1)

Wall Plate (x1)

M-A

M5x14 (x4)

M-F

Washer (x4)

M-B

M6x14 (x4)

M-G

Small Spacer (x8)

M-H

Large Spacer (x4)

M-C

M8x20 (x4)

M-D

M6x30 (x4)

M-E

M8x30 (x4)

Anti-Skid Block (x2)

Adapter Bracket (x2)

Plastic Locking Piece (x2)

Hex Key (x1)

Lock (x1)

W-A

ST6.3x55 (x6)

W-B

Concrete Anchor (x6)

W-C

D6 Washer (x6)
