Owner’s Manual

Dual Flex-Arm

Desk Clamp, Aluminum

Model: DDR1732DAL

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR

PROPERTY DAMAGE MAY OCCUR!

75 x 75

100 x 100

32"

MAX

19.8 lb. x219.8 lb. x2

(9 kg x2)(9 kg x2)

MAXMAX

Español 11 • Français 21 • Русский 31 • Deutsch 41

Safety Instructions

Warranty and Product Registration

WARNING

• Do not begin the installation until you have read and understood the instructions and warnings contained in this

manual. If you have any questions regarding any of the instructions or warnings, please visit tripplite.com/support.

• This mount was designed to be installed and utilized ONLY as speciﬁed in this manual. Improper installation of this

product may cause damage or serious injury.

• This product should only be installed by someone of good mechanical ability, with basic building experience and a

full understanding of this instruction manual.

• Make sure that the mounting surface can safely support the combined load of the equipment and all attached

hardware and components.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws ﬁrmly, but do not over-tighten. Over-tightening screws can damage the items, greatly reducing their

holding power.

• This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of

5 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the

product, at its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO

EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED

WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE;

AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied

warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not

apply to you. This warranty gives you speciﬁc legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since

individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or ﬁtness of these devices for

any speciﬁc application.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite

product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice. Photos and illustrations may differ slightly from actual

products.

NOTE: Read the entire instruction manual before you start assembly and installation.

Component Checklist

IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing.

If any parts are missing or faulty, visit tripplite.com/support for service.

Package P

Package W Package M

(x1)

(x2)

(x1)

(x2)

(x1)

(x2)

(x4)

4 mm (x1)

6 mm (x1)

M6x10 (x4)

M6x12 (x4)

M6x16 (x3)

M-A

M4x12 (x4)

M-B

M5x12 (x4)

M-C

D5 (x4)
