Side 1/16

Owner’s Manual

Medical-Grade

Mobile Power Retrofit Kit

Models: HCRK-54 & HCRK-36

Kit Includes: Power Supply Module, Battery Module (HCRK-54 = 54 amp-hour;

HCRK-36 = 36 amp-hour), Remote User Interface (RUI),

PowerAlert Data-Saving Software, Mounting Hardware and Cables.

Fully tested, certified and compliant with:

• UL 60601-1 • CAN/CSA-C22.2 No. 601.1-M90 • UL 1778 by

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

Mounting (Power Supply & Battery Module) 3

Connection / Start-Up 8

Operation 10

Features 11

Troubleshooting 13

Storage & Service 14

Safety & Regulatory Statements 15

Warranty & Warranty Registration 15

Important Safety Instructions 2

WARRANTY

REGISTRATION:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

200910241 93-2704-EN.indd 1 5/17/2010 5:16:47 PM

Important Safety Instructions

Tripp Lite’s Medical-Grade, Mobile Power Retrofit Kit includes two modules: a Power Supply Module and

a Battery Module. When the two modules are connected (and attached to a remote user interface), they

provide AC power for a variety of equipment on mobile carts. The following instructions refer to the kit as

a single unit as well as its component parts.

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation, operation

and storage of all Tripp Lite Medical-Grade, Mobile Power Retrofit Kits. Failure to heed these warnings

may affect your warranty.

Power Supply Module & Battery Module Location Warnings

• Your Power Supply Module incorporates fusing only in the ungrounded phase conductor. UL 60601-1

certified Power Supply Modules must not be used in countries other than the United States and Canada

and must be used only in health care facilities on grounded systems where conditions of maintenance

and supervision ensure that only qualified persons will service the electrical distribution system.

• Install your Power Supply Module and Battery Module indoors, away from excess moisture or heat, dust

or direct sunlight and conductive contaminants.

• Although the Power Supply Module is designed to support computer equipment, do not install it in direct

contact with magnetic storage media, as this may result in data corruption.

• For best performance, keep the indoor temperature between 32º F and 104º F (0º C and 40º C).

• Leave adequate space around all sides of the Power Supply Module and Battery Module for

proper ventilation.

Power Supply Module Connection Warnings

• Do not operate the Power Supply Module without connecting it to a Battery Module and the Remote

User Interface (RUI). The Power Supply Module will not operate (with or without utility power) until

the Battery Module and RUI are connected.

• Do not allow objects to contact the Power Supply Module’s two DC input terminals. Do not short or

bridge these terminals together. Serious personal injury or property damage could result.

• Connect your Power Supply Module directly to a properly grounded AC power outlet. Do not plug the

Power Supply Module into itself; this will damage the unit. The Power Supply Module features a

hospital-grade plug. If the plug is connected to a wall outlet that is not hospital-grade, the unit may not

be properly grounded.

• Do not modify the Power Supply Module’s plug, and do not use an adapter that would eliminate

the Power Supply Module’s ground connection.

• Do not use extension cords to connect the Power Supply Module to an AC outlet.

• If the Power Supply Module receives power from a motor-powered AC generator, the generator must

provide clean, filtered, computer-grade output.

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can reasonably be

expected to cause the failure of the life support equipment or to significantly affect its safety or

effectiveness is not recommended. Do not use this equipment in the presence of a flammable anesthetic

mixture with air, oxygen or nitrous oxide.

• The Power Supply Module is designed to accept connection of equipment mounted on the same mobile

cart. Connecting equipment which is not mounted on the same cart as the Power Supply Module could

pose a safety hazard.

• Do not connect surge suppressors or extension cords to the output of your Power Supply Module. This

may damage the Power Supply Module and may affect the surge suppressor and Power Supply Module

warranties.

200910241 93-2704-EN.indd 2 5/17/2010 5:16:47 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteri
Modell:	HCRK-36
Vekt:	32800 g
Støynivå:	- dB
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	32210 g
Sertifisering:	UL 60601-1, CAN/CSA-C22.2 No. 601.1-M90, UL 1778
Dimensjoner (B x D x H):	609.6 x 660.4 x 330.2 mm
Toppeffekt:	750 W
AC-inngangsspenning:	120 V
AC-inngangsfrekvens:	60 Hz
Produktfarge:	Sort
Pakkedybde:	375.9 mm
Pakkehøyde:	472.4 mm
Pakkebredde:	459.7 mm
Harmonisert system (HS)-kode:	8504.40.8500
I/O-porter:	NEMA 5-15P-HG
Strømbeskyttelsesfunksjoner:	Overbelastning
Total strøm:	300 W
Masterkassens (ytterkassens) bruttovekt:	32210 g
Masterkassens (ytterkassens) lengde:	375.9 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	459.7 mm
Masterkassens (ytterkassens) høyde:	472.4 mm
