Owner’s Manual

Purchased product

may differ from image.

Models:

MTB3-DOCK-03

MTB3-DOCK-03INT

Thunderbolt 3 Docking Station

with Dual 4K Video

Español 9

Français 18

Deutsch 26

Italiano 34

• For use with Mac OS and Windows host computers via either Thunderbolt 3 or

Multi-Function DisplayPort (MFDP) USB-C ports (product features vary based on

port type, see Specications Table for exact product features).

• Thunderbolt 3 input port supports data transfer rates up to 40 Gbps when used

with a Thunderbolt 3-enabled host computer; data transfer rates up to 26.2 Gbps

are supported via a MFDP-enabled host computer.

• Included 120W DC power supply provides up to 20V 3A (60W) to the host device.

• MTB3-DOCK-03INT includes 120W DC power supply with AUS, EU, UK and US

plugs for international use.

• Thunderbolt 3 output port supports daisy-chaining up to six devices with source

capability of 15W (5V 3A), and supports Thunderbolt 3-enabled devices such as

monitors, RAID memory and more*.

• DisplayPort connector supports 4-Lane DP1.4 video resolutions up to 8K

(7680 x 4320) @ 30 Hz when used with a Thunderbolt 3-enabled host computer

and 2-Lane DP1.4 video resolutions up to 4K (3840 x 2160) @ 60 Hz via a

MFDP-enabled host computer (requires DP1.4 Alt Mode)**.

• Supports DisplayPort Multi-Stream Transport (MST) Mode to allow two displays

to be connected, one to the Thunderbolt 3 output port and a second to the

DisplayPort connector for combined resolutions of 8K @ 30 Hz + 4K @ 30 Hz, or

dual 4K @ 60 Hz.

Note: See Multi-Monitor Requirements for details.

• RJ45 port supports Gigabit Ethernet speeds to connect to a wired network.

• Includes two USB 3.2 Gen 2 Type-A ports, both of which support 10 Gbps data

transfer speeds. One USB-A port supports charging speeds up to 5V 1.5A and the

other supports charging up to 5V 900mA.

• Includes one USB 3.2 Gen 2 Type-C port that supports 10 Gbps data transfer

speed and USB charging up to 5V 1.5A.

• Includes one 3.5 mm audio jack for stereo audio with auto-detection and auto-

switching between OMTP and CTIA.

• SD 4.0 and Micro SD 4.0 slots are available for memory cards. Both can be used

simultaneously.

• Plug-and-play; drivers are automatically downloaded and installed during the initial

dock connection with the host computer.

Note: The host must have administrative access for the drivers to install automatically. If this is

not possible, the drivers can be downloaded manually via the product’s webpage at

Tripplite.Eaton.com.

*Only applies to Thunderbolt 3 devices, USB Type-C devices are not supported in the chain.

** If using a USB-C host device that only supports DP 1.2 Alt Mode instead of DP 1.4, the

maximum video resolution supported is 4K/30 Hz.

Product Features

System Requirements

Package Includes

Optional Accessories

• Windows or Mac OS computer with Thunderbolt 3 or Multi-Function DisplayPort

(MFDP)-enabled USB Type-C port

• DisplayPort or Thunderbolt 3 compatible monitor

• Ethernet network with speeds up to 10/100/1000 Mbps

Note: Drivers are automatically downloaded and installed during the initial dock connection with

the host computer. The host must have administrative access for the drivers to install automatically.

If this is not possible, the drivers can be downloaded manually via the product’s webpage at Tripplite.

Eaton.com.

• MTB3-DOCK-03 or MTB3-DOCK-03INT

• Thunderbolt 3 Cable, M/M, 1.6 ft. (0.5m)

• External Power Supply (Input: 100-240V, 50/60 Hz, 3.0A,

Maximum Output: 20V 6A)

• International Power Adapters (AUS, EU, UK, US), (MTB3-DOCK-03INT only)

• Owner’s Manual

• MTB3-Series 40 Gbps Active Thunderbolt 3 Cables

• N201-Series Cat6 Gigabit Snagless Patch Cables

• P580-Series DisplayPort Cables

• U322-Series USB 3.0 A/B Cables

• U326-Series USB 3.0 Micro-B Device Cables

• U420-003-G2-5A USB 3.1 Gen 2 USB-C M/M Cable (3 ft.)

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	MTB3-DOCK-03INT
Vekt:	1530 g
Bredde:	80 mm
Dybde:	148 mm
Høyde:	17.5 mm
LED-indikatorer:	Data, Power
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	DC
Opprinnelsesland:	Vietnam
Pakkevekt:	1540 g
Hodetelefonutganger:	1
Sertifisering:	CCC; CE; GS; TUV; WEEE; cUL, RoHS; CE (Europe); REACH; FCC (USA)
HDCP:	Ja
Antall DisplayPorts:	1
Antall per pakke:	1 stykker
Kombinert hodetelefon/mikrofonport:	Ja
Utgangsstrøm:	20 V
Vertsgrensesnitt:	Thunderbolt 3
DisplayPort-versjon:	1.4
HDCP-versjon:	1.4/2.2
Antall skjermer som støttes:	2
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Ladefunksjon:	Ja
Visningsmoduser:	Extended, Mirror
Dataoverføringshastighet:	40 Gbit/s
Produktfarge:	Black, Grey
HD-type:	8K Ultra HD
Pakkedybde:	254 mm
Pakkehøyde:	71.1 mm
Pakkebredde:	160 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Hodetelefontilkobling:	3,5 mm
Kabler inkludert:	Thunderbolt
Maksimal digital oppløsning:	7680 x 4320 piksler
Mikrofon, linje-inn-støpsel:	Nei
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Bærekraftsertifikater:	CCC, CE, Federal Communications Commission (FCC), REACH, RoHS, WEEE
Innebygd kortleser:	Ja
Harmonisert system (HS)-kode:	8525.50.3035
Kroppsmateriale:	Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 85
AC-adapter bunt:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	1
Bærekraftsamsvar:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	2
Masterkassens (ytterkassens) bruttovekt:	8030 g
Masterkassens (ytterkassens) lengde:	391.2 mm
Produkter per masterkasse (ytterkasse):	5 stykker
Masterkassens (ytterkassens) bredde:	271.8 mm
Masterkassens (ytterkassens) høyde:	182.9 mm
Innput-strøm:	2 A
USB Power Delivery opp til:	60 W
Strømkabelens lengde:	1.2 m
Thunderbolt 3-porter antall:	2
