Side 1/12
Quick Start Guide
Industrial Cat5e/6,
USB 3.0 and 4K HDMI
Connectivity Solutions
Model Series: N206-XXXX-IND, P569-XXX-IND and U325-XXX-IND
See page 2 for a complete model listing.
Tripp Lite’s N206-Series Industrial Cat5e/6, U325-Series Industrial USB 3.0 and
P569-Series Industrial 4K HDMI connectivity solutions comply with the IP44 standard
protection against invasive dust, dirt and sand, and submersion
in up to 1.5 m of water for 60 minutes.
Note: Certain product combinations are needed to achieve IP44 and/or IP68 standards.
See section for more information.4. Product Combinations for IP44 and IP68 Protection
Este guía esta disponible en español en la página de Tripp Lite:
tripplite.com/support
Ce guide est disponible en français sur le site Web de Tripp Lite :
tripplite.com/support
Русскоязычная версия настоящего краткого руководства представлена
на веб-сайте компании Tripp Lite по адресу: tripplite.com
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
08-261-933773-EN.indd 1 11/14/2019 3:18:39 P
2
Table of Contents
Industrial Connectivity Solutions Complete Product Listing 2
1. N206-SB01-IND Surface Box Dimensions 3
2. Industrial Bulkhead Coupler Installation 4
(N206-BC01-IND, U325-000-IND and P569-000-FF-IND)
3. Industrial Keystone Jack Installation (N206-KJ01-IND) 6
4. Product Combinations for IP44 and IP68 Protection 9
Warranty and Product Registration 10
Industrial Connectivity Solutions
Complete Product Listing
Industrial Faceplates
N206-FP01-IND (1 Cutout)
N206-FP02-IND (2 Cutouts)
N206-FP04-IND (4 Cutouts)
Industrial Surface Mount Box
N206-SB01-IND
Bulkhead Couplers and
Keystone Jacks
N206-BC01-IND
(Cat5e/6 Bulkhead Coupler)
N206-KJ01-IND (Keystone Jack)
U325-000-IND (USB 3.0 Coupler)
P569-000-FF-IND (4K HDMI Coupler)
Industrial Patch Cables
N206-PC03-IND
(3 ft. Cat5e/6 Patch Cable)
N206-PC10-IND
(10 ft. Cat5e/6 Patch Cable)
N206-PC16-IND
(16 ft. Cat5e/6 Patch Cable)
N206-PC23-IND
(23 ft. Cat5e/6 Patch Cable)
N206-PC33-IND
(33 ft. Cat5e/6 Patch Cable)
N206-PC5O-IND
(50 ft. Cat5e/6 Patch Cable)
Industrial USB 3.0 Cables
U325-003-IND (3 ft. USB 3.0 Cable)
U325-006-IND (6 ft. USB 3.0 Cable)
U325-01O-IND (10 ft. USB 3.0 Cable)
U325-013-IND (13 ft. USB 3.0 Cable)
Industrial 4K HDMI Cables
P569-003-IND (3 ft. 4K HDMI Cable,
1 water-resistant connector)
P569-006-IND (6 ft. 4K HDMI Cable,
1 water-resistant connector)
P569-010-IND (10 ft. 4K HDMI Cable,
1 water-resistant connector)
P569-012-IND (12 ft. 4K HDMI Cable,
1 water-resistant connector)
P569-003-IND2 (3 ft. 4K HDMI Cable,
2 water-resistant connectors)
P569-006-IND2 (6 ft. 4K HDMI Cable,
2 water-resistant connectors)
P569-010-IND2 (10 ft. 4K HDMI
Cable, 2 water-resistant connectors)
P569-012-IND2 (12 ft. 4K HDMI
Cable, 2 water-resistant connectors)
Waterproof Cable Assembly Kit
N206-WK01-IND
08-261-933773-EN.indd 2 11/14/2019 3:18:39 P
3
1. N206-SB01-IND Surface Mount Box Dimensions
Dimensions: [mm] INCHES
Knockout for 0.5"
(M16) Cable
Knockout for 1.25"
(M32) Conduit
[Ø 25]
Ø 1
[50]
2
[24]
1
[120]
4.7
[Ø 32]
Ø 1.25
[80]
3
[80]
3
[50]
2
[107]
4.2
[32]
1.25
[Ø 13]
Ø 0.5
08-261-933773-EN.indd 3 11/14/2019 3:18:39 P
