Quick Start Guide

Package Contents

Installation

Pre-Configured Cat6 Surface-Mount Box

Models: N236-004-WH, N236-006-WH

Note: N236-006-WH model shown in the installation diagrams. Installation for the N236-004-WH model is the same.

Español 5 • Français 9 • Русский 13

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

• N236-004-WH or N236-006-WH Cat6 Surface-Mount Box

• Double-Sided Tape (x2)

• Cable Ties

o N236-004-WH (x4)

o N236-006-WH (x6)

• Screws (x2)

Use a flathead screwdriver to carefully pry apart the unit’s

housing.

Strip the Cat6 cable’s PVC jacket 1 ¼ inches (30 mm).

Separate the cable wires into four pairs.

1 ¼ in. (30 mm)

17-11-379-933737.indb 1 1/23/2018 5:00:22 PM

Installation

Follow the instructions on the color code sticker to position T568B or T568A wiring

Insert the four wire pairs into the slots accordingly

Use a punch-down tool (such as Tripp Lite model N046-000) to

complete the terminations and cut off any excess wire.

Once all cables are secured to the unit’s housing, reattach the

unit’s top cover.

Use the included cable ties to secure the Cat6 cables to the

unit’s housing.

A B
