Owner’s Manual

10/100 Media Converters

Models: N784-001-SC-MM (850 nm),

N784-001-SC-15 (1310 nm)

10/100/1000 Media Converters

Models: N785-001-LC-MM (850 nm),

N785-001-SC-MM (850 nm),

N785-001-SC (1310 nm)

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

All trademarks are the property of their respective owners.

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 11 • Français 21

21-01-265-933DEC.indd 121-01-265-933DEC.indd 1 7/30/2021 11:20:22 AM7/30/2021 11:20:22 AM

Product Features

• N784-001-SC-15 extends a 10/100 Mbps

Ethernet connection over singlemode ﬁber cable

up to 15 km

• N784-001-SC-MM extends a 10/100 Mbps

Ethernet connection over multimode ﬁber cable

up to 550 m

• N785-001-SC extends a 10/100/1000 Mbps

Ethernet connection over multimode ﬁber cable

up to 2 km

• N785-001-LC-MM and N785-001-SC-MM extend

a 10/100/1000 Mbps Ethernet connection over

multimode ﬁber cable up to 550 m

• LED indicators monitor Ethernet and ﬁber link status

• Supports both full-duplex and half-duplex operation

• Supports Auto MDI/MDI-X

Package Contents

• Media Converter

• External Power Supply with NEMA 1-15P Plug

• Owner’s Manual

21-01-265-933DEC.indd 221-01-265-933DEC.indd 2 7/30/2021 11:20:22 AM7/30/2021 11:20:22 AM

Optional Accessories

• N001-Series Cat5e Snagless Patch Cables

• N201-Series Cat6 Snagless Patch Cables

• N306-Series Duplex Multimode 62.5/125

Fiber Patch Cables (SC/SC)

• N320-Series Duplex Multimode 62.5/125

Fiber Patch Cables (LC/LC)

• N356-Series Duplex Singlemode 8.3/125

Fiber Patch Cables (SC/SC)

• N506-Series Duplex Multimode 50/125

Fiber Patch Cables (SC/SC)

• N520-Series Duplex Multimode 50/125

Fiber Patch Cables (LC/LC)

Installation

Note:

1. The following installation instructions refer to an installation

in which two media converters are used.

2. The installation diagram on the next page features a

N784-001-SC-MM. Connections are the same for all

models, with only the specs of the media converter being

different. (See the Speciﬁcations section in this manual for

details on your media converter.)

3. To avoid damage due to Electrostatic Discharge (ESD), it

is recommended you handle the product while wearing

an ESD wrist grounding strap or by touching a conductive

surface (such as metal) to discharge any potential ESD prior

to handling the product.

21-01-265-933DEC.indd 321-01-265-933DEC.indd 3 7/30/2021 11:20:22 AM7/30/2021 11:20:22 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	N784-001-SC-15
LED-indikatorer:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Opprinnelsesland:	China
Pakkevekt:	180 g
Inngangsspenning:	100 - 240 V
Bølgelengde:	1310 nm
Utgangsstrøm:	5 V
Maksimal dataoverføringshastighet:	100 Mbit/s
Auto MDI/MDI-X:	Ja
AC-inngangsfrekvens:	50 - 60 Hz
Fiberoptisk kontakt:	SC
Produktfarge:	Sort
Pakkedybde:	70.1 mm
Pakkehøyde:	50.8 mm
Pakkebredde:	25.9 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Ethernet-grensesnittype:	Raskt Ethernet
Intern:	Nei
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332184136
Masterkassens (ytterkassens) bruttovekt:	4500 g
Masterkassens (ytterkassens) lengde:	275.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	254 mm
Masterkassens (ytterkassens) høyde:	305.1 mm
Maksimal overføring avstand:	15000 m
Tosidig system:	Full, Half
Fibermodusstruktur:	Enkeltmodus
Omformer-inngangsgrensesnitt:	100Base-TX
