Side 1/347

system, or transmitted in any form or by any means, whether electronic, mechanical, photo

copying, recording or otherwise, without the prior written permission of the publisher.

FCC WARNING

This equipment has been tested and found to comply with the limits for a class A

device, pursuant to part 15 of FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a commercial installation.

This equipment generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communication. Operation of this equipment in a residential

area is likely to cause harmful interference, in which case, the user will be required

to correct the interference at the user’s own expense.

This is a Class A product. In a domestic environment, this product may cause radio

interference in which case the user may be required to take adequate measures.

HOT & COLD WARNING

The Switch surface will be getting very hot or cold depend on the operating

environment. Please take special care when touch to the working switch.

Take special care to read and understand all the content in the warning

boxes.

Take special care to read and understand all the content in the warning

boxes.

Warning

Do not work on the system or connect or disconnect cables during

periods of lightning activity.

Before working on equipment that is connected to power lines, remove

jewelry (including rings, necklaces, and watches). Metal objects will

heat up when connected to power and ground and can cause serious

burns or weld the metal object to the terminals.

Do not stack the chassis on any other equipment. If the chassis falls, it

can cause severe bodily injury and equipment damage.

An exposed wire lead from a DC-input power source can conduct

harmful levels of electricity. Be sure that no exposed portion of the DC-

input power source wire extends from the terminal block plug.

Ethernet cables must be shielded when used in a central office

environment.

If a redundant power system (RPS) is not connected to the switch,

install an RPS connector cover on the back of the switch.

Read the wall-mounting instructions carefully before beginning

installation. Failure to use the correct hardware or to follow the correct

procedures could result in a hazardous situation to people and damage

to the system.

Warning

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	netverkskort/adapter
Modell:	NGI-M08POE8-L2
Vekt:	960 g
Bredde:	50 mm
Dybde:	119.9 mm
Høyde:	160 mm
LED-indikatorer:	Ja
Antall USB 2.0-porter:	1
Strømforbruk (maks.):	240 W
Sertifisering:	FCC, TAA
Nettverksstandard:	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Auto MDI/MDI-X:	Ja
10G støtte:	Nei
Konsollport:	RJ-45
DHCP-funksjoner:	DHCP snooping
Auto-forhandling:	Ja
Jumbo rammer:	10000
DIN-skinnemontering:	Ja
Produktfarge:	Sort
Strømforbruk (vanlig bruk):	15 W
Driftstemperatur (T-T):	-40 - 75 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 85 °C
Lagringsrelativ fuktighet:	5 - 95
Bærekraftsertifikater:	CE, REACH, RoHS
tilbakestillingsknapp:	Ja
Kroppsmateriale:	Aluminium
Driftshøyde:	0 - 2000 m
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	SNMP
Ethernet-kobberkabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Relativ luftfuktighet under drift (H-H):	5 - 95
Svitsjtype:	Håndtert
Antall Basic switching RJ-45 Ethernet-ports:	8
Basic switching RJ-45 Ethernet ports-type:	Gigabit Ethernet (10/100/1000)
Størrelse på adressetabell:	16000 oppføringer
Ruting/svitsjekapasitet:	16 Gbit/s
Strømforsyning medfølger:	Ja
Strøm over Ethernet (PoE):	Ja
Power over Ethernet (PoE) effekt per port:	30 W
Antall Power over Ethernet plus (PoE+)-ports:	8
DC inngående spenning:	24 - 57 V
Jumbo Frames-støtte:	Ja
Full tosidig:	Ja
Total Power over Ethernet (PoE)-budsjett:	240 W
Innput-strøm:	5.8 A
Strømtilkobling:	Terminalblokk (6 pinner)
MAC-adresse automatisk læring støttes:	Ja
Strømbryterbelegg:	L2
Kringkasting stormkontroll:	Ja
