Owner’s Manual

1-Port Gigabit PoE+

Water-Resistant Extender

Model: NPOE-EXT-1G30WP

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

All trademarks are the property of their respective owners.

WARRANTY REGISTRATION

ISOBAR surge protector in our monthly drawing!

www.tripplite.com/warranty

Español 12 • Français 23 • Русский 34

Package Includes

Product Features

• NPOE-EXT-1G30WP Gigabit PoE+ Extender

• (x2) Water-Resistant Covers

• Owner’s Manual

• Save time and money by extending data and power over existing network

cables past the 100 m (328 ft.) limit

• Extend a 10/100/1000 Mbps application over longer distances by

cascading multiple extenders up to 500 m (1640 ft.)

• Supports all IEEE 802.3at- and IEEE 802.3af-compliant PoE/PoE+

devices (wireless LAN access points and bridges, VoIP, IP surveillance

cameras)

• Automatically detects and protects PoE/PoE+ equipment from being

damaged by incorrect installation (non-PoE devices only receive data)

• Compact aluminum case is IP65 rated for protection against water

splashes

• Plug and play—no additional power required

• Compact, wall-mountable design

RJ45 Cable Wire and Crimp Steps

1. Strip an inch or so of the outer skin of a Cat5e/6 cable with a utility

knife. Separate and straighten the internal wires, and arrange them in

the proper order. Use a wire cutter to trim the wires evenly. Slide one of

the included water-resistant covers along the end of the cable.

2. Insert the neatly trimmed wires into an RJ45 modular connector plug

(such as Tripp Lite’s N230-100) in the correct order. Use your crimping

tool (such as Tripp Lite’s T100-001-TST) to press the cable jacket and

the wires into the RJ45 connector. Be sure to test the connection to

ensure the cable is working properly.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	NPOE-EXT-1G30WP
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	110 g
Sertifisering:	CE, FCC, REACH
Nettverksstandard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Produktfarge:	Sølv
Pakkedybde:	80 mm
Pakkehøyde:	45 mm
Pakkebredde:	154.9 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	-10 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 70 °C
Lagringsrelativ fuktighet:	0 - 95
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85044095
Kan monteres på vegg:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet-grensesnittype:	Fast Ethernet, Gigabit Ethernet
Relativ luftfuktighet under drift (H-H):	0 - 90
Strøm over Ethernet (PoE):	Ja
Power over Ethernet (PoE) effekt per port:	30 W
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332236132
Masterkassens (ytterkassens) bruttovekt:	1150 g
Masterkassens (ytterkassens) lengde:	190 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	249.9 mm
Masterkassens (ytterkassens) høyde:	175 mm
Strømforsyning via Ethernet/Power over Ethernet (PoE):	- V
Kabeltyper som støttes:	Cat5e, Cat6, Cat6a
