Side 1/8

Owner’s Manual

VGA + Audio to HDMI

Adapter/Scaler

Model: P116-000-HDSC1

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

• Combines VGA video and 3.5 mm mini-stereo audio

signals for use with an HDMI display

• Supports VGA input video resolutions up to 1920 x 1440

• Built-in scaler allows the VGA input signal to be

displayed in 720p or 1080p on an HD monitor

• Supports 24-bit True Color (8-bits per channel)

• Supports HDMI bandwidth of 165MHz/1.65 Gbps per

channel

15-05-051-933454.indd 1 5/15/2015 10:45:54 AM

Package Includes

System Requirements

Optional Accessories

• P116-000-HDSC1

• External Power Supply

(Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A)

• Owner’s Manual

• Computer with a VGA video port and 3.5 mm

mini-stereo audio port

• Display with an HDMI port

• P312-Series 3.5 mm Mini-Stereo Audio Cables

• P502-Series VGA Monitor Cables with RGB Coax

• P568-Series High Speed HDMI Cables

15-05-051-933454.indd 2 5/15/2015 10:45:54 AM

Installation

Note: Make sure all devices you are connecting are powered

off prior to installation.

1. Connect the VGA port on your computer to the unit’s

VGA input port using a VGA video cable.

2. Connect the 3.5 mm mini-stereo port on your

computer to the unit’s 3.5 mm mini-stereo input port

using a 3.5 mm mini-stereo cable.

3. Connect the HDMI output port on the unit to the HDMI

port on your display using an HDMI cable.

4. Connect the power supply to the unit and plug it into

a Tripp Lite Surge Protector, Power Distribution Unit

(PDU), or Uninterruptible Power Supply (UPS).

5. Power on the connected devices.

6. By default, the unit displays 720p video on the

monitor. To toggle to 1080p, press the 720p/1080p

button on the unit using a small, pointed object such

as a paperclip.

15-05-051-933454.indd 3 5/15/2015 10:45:54 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	P116-000-HDSC1
Vekt:	50 g
Bredde:	55.9 mm
Dybde:	58.4 mm
Høyde:	22.9 mm
Bruksanvisning:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	160 g
Maksimal videooppløsning:	1920 x 1440 piksler
Inngangsspenning:	100 - 240 V
Fargedybde:	24 bit
Vertsgrensesnitt:	VGA (D-Sub) + 3.5 mm (1/8")
Båndbredde:	165 MHz
Utgangsgrensesnitt:	HDMI
Produktfarge:	Hvit
Pakkedybde:	125 mm
Pakkehøyde:	59.9 mm
Pakkebredde:	169.9 mm
Støttede videofunksjoner:	720p, 1080p
Driftstemperatur (T-T):	0 - 70 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 80 °C
Lagringsrelativ fuktighet:	5 - 95
Inngangsfrekvens:	50/60 Hz
Ekstern strømadapter:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332188332
Masterkassens (ytterkassens) bruttovekt:	1900 g
Masterkassens (ytterkassens) lengde:	264.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	309.9 mm
Masterkassens (ytterkassens) høyde:	190 mm
Driftsstrøm:	0.5 A
