Owner’s Manual

VGA + Audio to HDMI

Adapter/Scaler

Model: P116-000-HDSC2

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

• Combines a VGA video and RCA stereo audio signal for

use with an HDMI display

• Supports VGA input video resolutions up to 1920 x 1440

• Built-in scaler allows the VGA input signal to be

displayed in 720p or 1080p on an HD monitor

• Supports 24-bit True Color (8-bits per channel)

• Supports HDMI bandwidth of 165MHz/1.65 Gbps per

channel

15-05-048-933453.indd 1 5/15/2015 9:48:39 AM

Package Includes

System Requirements

Optional Accessories

• P116-000-HDSC2

• External Power Supply

(Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A)

• Owner’s Manual

• Source with a VGA video port and RCA stereo* ports

• Display with an HDMI port

*A 3.5 mm to (x2) RCA adapter cable can be used to connect

a 3.5 mm mini-stereo port to the unit’s RCA ports

• A050-006 RCA Stereo Audio Cable

(x2 RCA M/M) – 6 ft.

• A060-Series RCA Audio Cable (RCA M/M)

• P314-Series 3.5 mm Mini-Stereo to (x2) RCA Stereo

Audio Adapter Cables

• P502-Series VGA Monitor Cables with RGB Coax

• P568-Series High Speed HDMI Cables

15-05-048-933453.indd 2 5/15/2015 9:48:39 AM

Installation

Note: Make sure all devices you are connecting are powered

off prior to installation.

1. Connect the VGA port on the source to the unit’s VGA

input port using a VGA video cable.

2. Connect the RCA stereo ports* on the audio source to

the unit’s RCA stereo input ports using an RCA stereo

cable.

3. Connect the HDMI output port on the unit to the HDMI

port on your display using an HDMI cable.

4. Connect the power supply to the unit and plug it into

a Tripp Lite Surge Protector, Power Distribution Unit

(PDU), or Uninterruptible Power Supply (UPS). The

red LED on the VGA-side of the unit will illuminate to

indicate that power is being received.

5. Power on the connected devices.

6. By default, the unit displays 720p video on the

monitor. To toggle to 1080p, press the 720p/1080p

button on the HDMI-side of the unit. The red LED on

the HDMI-side will illuminate to indicate that a 720p

image is being displayed and will be off when a 1080p

image is being displayed.

*A 3.5 mm to (x2) RCA adapter cable can be used to connect

a 3.5 mm mini-stereo port to the unit’s RCA ports

15-05-048-933453.indd 3 5/15/2015 9:48:39 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Ikke kategorisert
Modell:	P116-000-HDSC2
Vekt:	140 g
Bredde:	88.9 mm
Dybde:	71.1 mm
Høyde:	25.4 mm
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	910 g
Sertifisering:	RoHS
Maksimal videooppløsning:	1920 x 1440 piksler
Inngangsspenning:	100 - 240 V
Fargedybde:	24 bit
Vertsgrensesnitt:	VGA (D-Sub)
Driftsspenning:	5 V
Utgangsgrensesnitt:	HDMI
Produktfarge:	Sort
Pakkedybde:	127 mm
Pakkehøyde:	61 mm
Pakkebredde:	170.2 mm
Støttede videofunksjoner:	720p, 1080p
Driftstemperatur (T-T):	0 - 70 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 80 °C
Lagringsrelativ fuktighet:	5 - 95
Inngangsfrekvens:	50 - 60 Hz
Ekstern strømadapter:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 85
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332188349
Masterkassens (ytterkassens) bruttovekt:	9480 g
Masterkassens (ytterkassens) lengde:	264.2 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	315 mm
Masterkassens (ytterkassens) høyde:	190.5 mm
Antall:	1
Driftsstrøm:	2 A
Omformertype:	Aktiv
