Side 1/8

Owner’s Manual

VGA to HDMI Adapter

with USB Audio

and Power

Model: P116-003-HD-U

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

15-06-265-93347C_EN.indd 1 6/24/2015 11:32:22 AM

Package Includes

Product Features

System Requirements

Optional Accessories

• P116-003-HD-U

• Owner’s Manual

• Converts VGA video and USB 2-channel audio signals

for use with an HDMI display

• Supports video resolutions up to 1920 x 1080 (1080p)

• Supports 24-bit True Color (8 bits per channel)

• Supports video transfer rates of 6.75 Gbps

(2.25 Gbps per channel)

• USB provides power—no external power supply required

• Source with VGA video and USB ports

• Display with an HDMI port

• P568-Series High-Speed HDMI Cables

15-06-265-93347C_EN.indd 2 6/24/2015 11:32:22 AM

Installation

Note: Make sure all devices you are connecting are powered

off prior to installation.

1. Connect the built-in VGA cable to the VGA port on your

computer.

2. Connect the built-in USB cable to the USB port on

your computer.

3. Connect the HDMI output port on the unit to the HDMI

port on your display using an HDMI cable.

4. Power on the connected devices. The LED will

illuminate Red to indicate it is connected, and then

turn Blue when it transmits video to the source.

5. Customize how video is displayed on the add-on

monitor using your computer’s display settings.

15-06-265-93347C_EN.indd 3 6/24/2015 11:32:22 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	P116-003-HD-U
Bruksanvisning:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	110 g
Maksimal videooppløsning:	- piksler
Fargedybde:	24 bit
Vertsgrensesnitt:	VGA (D-Sub) + USB
Utgangsgrensesnitt:	HDMI
Kabellengde:	1 m
Produktfarge:	Sort
Pakkedybde:	119.4 mm
Pakkehøyde:	25.4 mm
Pakkebredde:	160 mm
Støttede videofunksjoner:	1080p
Harmonisert system (HS)-kode:	84733080
USB-strøm:	Ja
Plugg inn og spill:	Ja
Største båndbredde for port:	6.75 Gbit/s
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332189407
Masterkassens (ytterkassens) bruttovekt:	1320 g
Masterkassens (ytterkassens) lengde:	170.2 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	322.6 mm
Masterkassens (ytterkassens) høyde:	134.6 mm
