Side 1/16

Quick Start Guide

VGA + Audio to HDMI

Adapter Cable (M/M), 6 ft.

Model: P116-006-HDMI-A

Español 5 • Français 9 • Русский 13

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

17-10-251-93370E.indb 1 10/13/2017 9:23:12 AM

Product Features

Installation

Package Contents

• All-in-one solution to connect a VGA + audio source to an HDMI

display

• Supports resolutions up to 1920 x 1080 @ 60 Hz

• HDCP 1.2 and HDMI 1.3 compliant

• Bus-powered via USB-A connector

• Plug-and-play—no software or drivers to install

Note: Make sure all devices you are connecting are powered off prior to installation.

1 Connect the VGA connector to the source’s VGA port.

2 Connect the 3.5 mm plug to the source’s audio jack.

3 Connect the built-in USB connector to a USB port on a USB charger or

VGA source.

4 Connect the HDMI connector to an HDMI display.

• P116-006-HDMI-A

• Quick Start Guide

17-10-251-93370E.indb 2 10/13/2017 9:23:12 AM

Warranty and Product Registration

Speciﬁcations

2-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of two

(2) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing

or replacing (at its sole option) any such defective products. To obtain service under this warranty, you

must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE

service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with

transportation charges prepaid and must be accompanied by a brief description of the problem encountered

and proof of date and place of purchase. This warranty does not apply to equipment, which has been

damaged by accident, negligence or misapplication or has been altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion

of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,

INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED

OF THE POSSIBILITY OF SUCH DAMAGE. Speciﬁcally, TRIPP LITE is not liable for any costs, such as lost proﬁts

or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes,

claims by third parties, or otherwise.

Connectors

HDMI HDMI (Male)

VGA HD15 (Male)

Audio 3.5 mm (Male)

USB USB-A (Male)

Environmental

Operating Temperature 32 to 104°F (0 to 40°C)

Storage Temperature -4 to 140°F (-20 to 60°C)

Storage Humidity 10% to 90% RH, Non-Condensing

17-10-251-93370E.indb 3 10/13/2017 9:23:12 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	P116-006-HDMI-A
Vekt:	140 g
Bredde:	177 mm
Dybde:	12.7 mm
Høyde:	228 mm
Maksimal oppløsning:	1920 x 1080 piksler
Opprinnelsesland:	China
Pakkevekt:	230 g
HDCP:	Ja
HDMI-versjon:	1.3
Tilkobling 1:	HDMI
Tilkobling 2:	VGA (D-Sub) + 3.5mm + USB Type-A
Kabellengde:	1.8 m
Produktfarge:	Sort
Pakkedybde:	228.6 mm
Pakkehøyde:	12.7 mm
Pakkebredde:	177.8 mm
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Støttede videofunksjoner:	1080p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Relativ luftfuktighet under drift (H-H):	10 - 90
Kontaktplettering:	Gull
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332203349
Masterkassens (ytterkassens) bruttovekt:	1450 g
Masterkassens (ytterkassens) lengde:	457.2 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	406.4 mm
Masterkassens (ytterkassens) høyde:	25.4 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hankjønn
