Owner’s Manual

HDMI to Composite Video

with Audio Converter

Model: P130-000-COMP

Español 5 • Français 9 • Русский 13

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

18-05-004-933781.indb 1 5/11/2018 9:11:29 AM

Optional Accessories

System Requirements

• P568-Series High-Speed HDMI Cables

• A004-006 Composite Video Cable, 6 ft.

• A050-006 R/L Stereo Audio Cable, 6 ft.

*Includes NEMA 1-15P (North America), CEE 7/16 Schuko (Europe), BS1363 (UK) and

AS/NZS 3112 (Australia) plugs

• HDMI-enabled audio/video source

• Composite video-enabled display device with R/L stereo audio

Package Includes

• P130-000-COMP

• External Power Supply*

(Input: 100-240V, 50/60 Hz,

0.3A; Output: 5V 1A)

• Mounting Hardware

• Owner’s Manual

Product Features

•

Converts an HDMI audio/video signal for use with composite video displays

• Supports uncompressed 2-channel stereo audio

• Allows you to enjoy high-quality image and sound when watching movies

or playing games on monitors and projectors equipped with composite

video ports

• Converts an HDMI source for display in NTSC or PAL

• Supports maximum output resolutions up to 480i (NTSC) or 576i (PAL)

• Supports maximum HDMI input resolutions up to 1080p

• International power supply includes NEMA 1-15P (North America),

CEE 7/16 Schuko (Europe), BS1363 (UK) and AS/NZS 3112 (Australia)

plugs

18-05-004-933781.indb 2 5/11/2018 9:11:29 AM

Speciﬁcation Value

Input Port HDMI, Female

Output Ports 1 x RCA Composite Video, Female

2 x RCA Stereo Audio, Female

Operating Temperature 32° to 113° F / 0° to 45° C

Storage Temperature 14° to 158° F / -10° to 70° C

Operating Humidity 10% to 85% RH, Non-Condensing

Storage Humidity 5% to 90% RH, Non-Condensing

External Power Supply Input: 100-240V, 50/60 Hz, 0.3A;

Output: 5V 1A

Power Consumption 5W Max.

Maximum Input Resolutions 1080p

Maximum Output Resolutions 480i (NTSC) and 576i (PAL)

Unit Dimension (H x W x D) 0.98 x 4.02 x 3.94 in. / 25 x 100 x 100 mm

Unit Weight 1.36 lb. / 0.6 kg

Installation

Note: Before installation, make sure all devices and components are powered off.

1. Mount the unit to a wall or other surface using the included Optional:

mounting hardware.

2. Connect the HDMI port on your source to the input port on the unit using

an HDMI audio/video cable.

3. Connect the composite video output port on the unit to the port on your

display using a composite video cable.

4. Connect RCA stereo audio cables from the output ports on the unit to the

audio device.

5. Connect the power supply to the unit and plug it into a Tripp Lite Surge

Protector, Power Distribution Unit (PDU) or Uninterruptible Power Supply

(UPS).

6. Power on the connected devices.

7. You can toggle between NTSC and PAL video modes using the switch on

the unit.

18-05-004-933781.indb 3 5/11/2018 9:11:30 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	lyd / video konverterer
Modell:	P130-000-COMP
Vekt:	620 g
Bruksanvisning:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	420 g
HDCP:	Ja
Maksimal videooppløsning:	- piksler
Inngangsspenning:	100 - 240 V
Vertsgrensesnitt:	3 x RCA
Utgangsgrensesnitt:	HDMI
Produktfarge:	Sort
Pakkedybde:	190 mm
Pakkehøyde:	55.1 mm
Pakkebredde:	220 mm
Analogt signalformatsystem:	NTSC, PAL
Kabler inkludert:	AC
Støttede videofunksjoner:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Inngangsfrekvens:	50/60 Hz
Ekstern strømadapter:	Ja
Inkluderte kraftpluggtyper:	AU, NA, UK
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332192735
Masterkassens (ytterkassens) bruttovekt:	4500 g
Masterkassens (ytterkassens) lengde:	290.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	395 mm
Masterkassens (ytterkassens) høyde:	235 mm
Driftsstrøm:	0.3 A
Omformertype:	Aktiv
