Side 1/20

Owner’s Manual

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

HDMI to DisplayPort 1.2a

Active Converter

Model: P130-06N-DP-V2

Espanol 6 • Francais 11 • Póññêèé 16

16-10-388-933672.indb 1 11/10/2016 3:55:52 PM

Features

Package Includes

System Requirements

Optional Accessories

• Connect an HDMI source to a DisplayPort

monitor

• Supports 4K x 2K video resolutions up to

4096 x 2160 @ 30Hz

• DisplayPort 1.2a compliant

• Supports 7.1 channel surround sound audio

• Built-in USB-A connector provides power,

if needed

• Plug-and-play; no software or drivers required

• P130-06N-DP-V2

• Owner’s Manual

• Computer or Blu-ray™ player with an HDMI

audio/video port

• Monitor with a DisplayPort

• P580-Series DisplayPort Cables

16-10-388-933672.indb 2 11/10/2016 3:55:52 PM

Installation

Speciﬁcations

Note: Make sure all devices to be connected are powered

off prior to installation.

1. Connect the converter’s built-in HDMI

connector to the HDMI source.

2. Using a DisplayPort cable (such as Tripp Lite’s

P580-Series), connect the converter’s

DisplayPort to the monitor’s DisplayPort.

3. Power on the connected devices.

4. If more power is required than the HDMI source

provides, plug the USB-A connector into a USB

source.

Speciﬁcation Value

Input Ports HDMI Male

USB-A Female (Power Only)

Output Port DisplayPort Female

Operating Temperature

32 to 113°F / 0 to 45°C

Storage Temperature 14 to 176°F / -10 to 80°C

Operating Humidity

10 to 85% RH, Non-Condensing

Storage Humidity

5 to 90% RH, Non-Condensing

Max Video Resolution 4096 x 2160 @ 30Hz

Unit Dimension

(H x W x D)

0.82 x 0.43 x 9.65 in.

20.8 x 11 x 245 mm

Unit Weight 0.09 lb. / 42g

16-10-388-933672.indb 3 11/10/2016 3:55:52 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	kabler for datamaskiner og annet
Modell:	P130-06N-DP-V2
Strømkilde:	USB
Bruksanvisning:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	80 g
HDCP:	Ja
DisplayPort-versjon:	1.2a
Tilkobling 1:	HDMI
Tilkobling 2:	DisplayPort
Kabellengde:	0.15 m
Produktfarge:	Sort
Pakkedybde:	119.4 mm
Pakkehøyde:	21.6 mm
Pakkebredde:	99.1 mm
Støttede grafikkoppløsninger:	4096 x 2160
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84733080
Plugg inn og spill:	Ja
Kontaktplettering:	Gull
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332200416
Masterkassens (ytterkassens) bruttovekt:	820 g
Masterkassens (ytterkassens) lengde:	256.5 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	111.8 mm
Masterkassens (ytterkassens) høyde:	119.4 mm
Connector 1 kjønn:	Hankjønn
Connector 2 kjønn:	Hunkjønn
